PDG23M0060TFFL - 60 Amp Circuit Breaker

PDG23M0060TFFL - 60 Amp Circuit Breaker

The Eaton PDG23M0060TFFL is a 60-amp, 3-pole molded case circuit breaker from the Power Defense family, designed for commercial and industrial electrical applications where dependable circuit protection is essential. This Frame 2 breaker has a 65 kA interrupting rating at 480 VAC and uses a fixed thermal-magnetic trip for overload and short-circuit protection. It also includes load-side lugs. If you're replacing an existing breaker, the details matter—especially the frame, amperage, pole count, trip type, voltage, and interrupting rating. With the PDG23M0060TFFL, you get a straightforward 60A breaker designed for three-phase applications and backed by recognized electrical certifications. Its combination of a compact frame and higher fault-current capability makes it a practical option for compatible distribution equipment, machinery, and other commercial or industrial power systems.

Key Features and Benefits

• 60A, 3-pole configuration for compatible three-phase electrical systems.
• 65 kAIC at 480 VAC provides the interrupting capacity needed for applications with higher available fault current.
• Fixed thermal-magnetic trip provides overload and short-circuit protection without electronic trip settings to configure.
• Frame 2 design offers a compact footprint for compatible Power Defense equipment.
• Load-side lugs are included in the breaker configuration.
• Part of the Eaton Power Defense molded case circuit breaker family.
• Clearly defined electrical ratings make it easier to compare against an existing breaker when planning a replacement.

Technical Specifications

• Manufacturer: Eaton

• Part Number: PDG23M0060TFFL

• Product Family: Power Defense

• Breaker Type: Molded Case Circuit Breaker (MCCB)

• Frame: Frame 2

• Poles: 3

• Amperage: 60A

• AIC Rating: 65kA at 480VAC

• Trip Type: Fixed Thermal-Magnetic

• Terminal Configuration: Load-Side Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• The PDG23M0060TFFL Power Defense circuit breaker is associated with recognized electrical standards and certifications, including UL 489, CSA, IEC 60947-2, and CCC requirements. It is also RoHS compliant, addressing restrictions on certain hazardous substances used in electrical and electronic products.
• Requirements can differ from one installation to another. Always confirm the applicable certification, electrical code, equipment listing, and manufacturer specifications before installing or replacing a circuit breaker.

Where It Works Best

• This breaker makes sense for commercial and industrial three-phase electrical systems that specifically call for a 60A, 3-pole molded case breaker with the appropriate Frame 2 configuration. Potential applications include compatible power distribution equipment, industrial machinery, control systems, and other electrical equipment requiring a 65 kA interrupting rating at 480 VAC.

• Replacing an existing PDG23M0060TFFL? Don't rely on amperage alone. Check the complete part number, frame, poles, voltage, AIC rating, trip type, lug configuration, and physical fit. A breaker can look similar and still have electrical or mechanical differences that make it unsuitable for a particular application.
