PDG23M0060TFFJ - 60 Amp Circuit Breaker

PDG23M0060TFFJ - 60 Amp Circuit Breaker

The Eaton PDG23M0060TFFJ is a 60-amp, 3-pole molded case circuit breaker from the Global Rated Power Defense line. This is a Frame 2 breaker with a 65kA interrupting rating at 480 VAC, a fixed trip, and line and load lugs. In practical terms, it's a good match to consider when the electrical equipment calls for this exact combination of amperage, poles, and interrupting capacity. The breaker measures 4.19 inches high, 6 inches wide, and 3.5 inches deep; these dimensions can also be checked against the equipment before installation. If you're replacing an existing PDG23M0060TFFJ, or trying to match a breaker to a specific application, don't stop at the 60A rating. Pole count, voltage, A.I.C. rating, trip type, connections, and physical fit all matter.

Key Features and Benefits

• 60-amp rating for applications that require a 60A breaker.
• 3-pole configuration for compatible three-pole electrical systems.
• Rated 65kA at 480 VAC for applications where this interrupting capacity is required.
• Fixed trip configuration keeps the setup straightforward.
• Line and load lugs are included with this breaker.
• Part of the Global Rated Power Defense, Frame 2 family.
• Compact dimensions make it easier to check the breaker against the available installation space.
• Clearly identified electrical ratings help take some of the guesswork out of matching a replacement breaker.

Technical Specifications

• Part Number: PDG23M0060TFFJ

• Type: Molded Case Circuit Breaker

• Product Family: Global Rated Power Defense

• Frame: Frame 2

• Poles: 3

• Amperage: 60A

• A.I.C. Rating: 65kA @ 480 VAC

• Trip Type: Fixed Trip

• Connections: Line & Load Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• Certification and material-compliance requirements aren't the same for every installation. When a job requires specific approvals or compliance documentation, check the manufacturer's documentation for the exact PDG23M0060TFFJ configuration. This avoids assuming that an approval applying to one breaker in a product family automatically applies to every configuration.

Where It Works Best

• This breaker is best suited for commercial and industrial electrical applications that require a 60A, 3-pole molded-case circuit breaker rated at 65kA at 480 VAC. This can include compatible electrical distribution equipment, machinery, facility electrical systems, and replacement or maintenance work.

• Replacing a breaker? Here's the part worth paying attention to: two breakers with the same amperage aren't necessarily interchangeable. Before using the PDG23M0060TFFJ, compare the full specifications with the equipment requirements. For this breaker, you're looking at 60 amps, 3 poles, 65kA at 480 VAC, fixed trip, and line and load lugs, along with a physical size of 4.19" H x 6.0" W x 3.5" D.
