PDG23M0050TFFJ - 50 Amp Circuit Breaker

PDG23M0050TFFJ - 50 Amp Circuit Breaker

The Eaton PDG23M0050TFFJ is a 50-amp, 3-pole molded case circuit breaker from the Global Rated Power Defense line. This is a Frame 2 breaker with a fixed trip and a 65kA interrupting rating at 480 VAC. Line and load lugs are included. It's a good match to consider when you're working on a compatible commercial or industrial electrical system and need these particular ratings. The breaker measures 4.19" high x 6.0" wide x 3.5" deep, which is useful to know when you're checking an existing installation or working with limited panel space. For replacement jobs, start with the PDG23M0050TFFJ part number, then compare the electrical and physical specs with the breaker being replaced. Amp rating alone isn't enough to determine a proper match.

Key Features and Benefits

• 50A fixed trip for applications requiring a 50-amp breaker
• 3-pole design for compatible three-phase electrical systems
• 65kA interrupting rating at 480 VAC
• Frame 2 molded case construction
• Includes line and load lugs
• Measures 4.19" H x 6.0" W x 3.5" D
• Straightforward fixed-trip design with no trip setting to adjust in the field

Technical Specifications

• Part Number: PDG23M0050TFFJ

• Type: Molded Case Circuit Breaker

• Product Line: Global Rated Power Defense

• Frame: Frame 2

• Amperage: 50A

• Poles: 3

• A.I.C. Rating: 65kA @ 480 VAC

• Trip: Fixed

• Lugs: Line & Load

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• Specific certification and material compliance information wasn't provided with the available specifications for this breaker. Those details should be checked against the product markings and current manufacturer documentation when they're required for a particular installation. This also avoids assuming that a certification applies when it hasn't been confirmed for the exact PDG23M0050TFFJ configuration.

Where It Works Best

• This breaker makes sense for commercial and industrial electrical applications that specifically call for a 50A, three-pole molded case breaker with a 65kA rating at 480 VAC. It may be used in compatible power distribution equipment, machinery, control equipment, and other three-phase electrical systems where its ratings and configuration meet the job requirements.

• If you're replacing a breaker that's already in service, check more than the number printed on the amp rating. Confirm the part number, frame size, pole count, voltage, interrupting rating, trip type, lugs, and dimensions against the existing equipment. Those details matter when determining whether the PDG23M0050TFFJ is actually the right fit.
