PDG23M0045TFFL - 45Amp Circuit Breaker

PDG23M0045TFFL - 45Amp Circuit Breaker

The Eaton PDG23M0045TFFL Power Defense Molded Case Circuit Breaker provides cutting-edge electrical protection and performance for demanding industrial and commercial applications. With a 45A rating and a breaking capacity of 65 kA at 480V, this globally rated Frame 2 breaker ensures reliable operation under high fault conditions. Designed with fixed thermal-magnetic trip units and standard load-only terminals, it is a versatile and durable choice for modern power distribution systems.

Key Features and Benefits

• High Interrupt Capacity: Breaking capacity of 65 kA at 480V (UL) and up to 100 kAIC at 240V (IEC), providing robust protection for high-demand systems.
• Fixed Thermal-Magnetic Trip Unit: Reliable overload and short-circuit protection ensures operational consistency without requiring manual adjustments.
• Easy Installation: Standard load-only terminals (PDG2X3T100) simplify the installation process, reducing downtime and maintenance efforts.

Technical Specifications

• Frame Type: Frame 2, Power Defense Series
• Poles: 3-pole
• Amperage Rating: 45A
• Voltage Rating: 600 Vac max
• Interrupt Ratings: 65 kAIC at 480V;åÊ100 kAIC at 240V;åÊ35 kAIC at 600V

• Weight: 1.82 kg
• Dimensions: 88.9 mm x 104.6 mm x 152.4 mm

Material Compliance and Certifications

• RoHS Compliance: Reflects Eaton's commitment to environmentally friendly manufacturing practices.
• Global Certifications: Meets rigorous international standards for safety and performance.

Suitability

• The Eaton PDG23M0045TFFL Circuit Breaker is ideal for high-demand applications in industrial facilities, commercial buildings, and data centers. Its advanced interrupt capabilities and durable construction make it a trusted choice for safeguarding critical electrical infrastructure.

For reliable protection, superior performance, and global compatibility, choose the Eaton PDG23M0045TFFL Circuit Breaker for your power distribution needs.
