PDG23M0035TFFL - 35 Amp Circuit Breaker

PDG23M0035TFFL - 35 Amp Circuit Breaker

When you're replacing a circuit breaker, getting the details right matters. The Eaton PDG23M0035TFFL is a 35A, 3-pole Power Defense molded case circuit breaker built on a Frame 2 platform. It has a 65 kA interrupting rating at 480 VAC, a fixed-trip design, and load lugs. That combination makes it a practical option for compatible commercial and industrial electrical equipment that requires these specific ratings.

The PDG23M0035TFFL measures approximately 4.19 inches high, 6 inches wide, and 3.5 inches deep so that you can compare its physical size with the available space in your equipment before installation. If you're replacing an existing breaker, check more than just the amperage. Matching the full part number, pole count, voltage, interrupting rating, frame, trip configuration, and connections can save you from ending up with a breaker that looks right but isn't right for the application.

Key Features and Benefits

• 35-amp rating for applications requiring 35A circuit protection
• 3-pole configuration for compatible three-pole electrical systems
• 65kA A.I.C. at 480 VAC for applications requiring this level of interrupting capacity
• Frame 2 Power Defense design
• Fixed trip, providing predetermined trip characteristics
• Load lugs included for compatible electrical connections
• Compact 4.19" H × 6.0" W × 3.5" D dimensions make it easier to check fit before installation
• Clearly defined ratings help contractors, electricians, and maintenance teams quickly compare the breaker with their equipment requirements

Technical Specifications

• Part Number: PDG23M0035TFFL

• Product Type: Molded Case Circuit Breaker

• Series: Power Defense

• Frame: Frame 2

• Poles: 3

• Amperage: 35A

• A.I.C. Rating & Voltage: 65kA @ 480 VAC

• Trip: Fixed

• Lugs: Load Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• The PDG23M0035TFFL is part of the Global Rated Power Defense molded-case circuit breaker family. If your installation has specific certification, regulatory, or material compliance requirements, confirm these requirements against the current product documentation and the breaker's markings before installation.

Where It Works Best

• The PDG23M0035TFFL is best suited for compatible commercial and industrial electrical applications requiring a 35A, 3-pole molded-case circuit breaker rated at 65kA at 480 VAC. Its specifications may make it suitable for compatible power distribution equipment, machinery, and control equipment, as well as for replacement applications where a Frame 2 breaker with a fixed trip and load lugs is called for.
