PDG23M0035TFFJ - 35A Circuit Breaker

PDG23M0035TFFJ - 35A Circuit Breaker

The Eaton PDG23M0035TFFJ is a versatile and high-performance molded case circuit breaker, purpose-built to deliver reliable circuit protection for demanding industrial and commercial applications. Featuring a globally rated PD2 frame, this three-pole breaker supports a 35Amp current capacity and a robust interrupting capacity of 65 kA at 480V. Equipped with a thermal-magnetic trip unit and standard line and load terminals, the PDG23M0035TFFJ ensures fast and accurate response to overloads and short circuits. Its compact dimensions and lightweight design facilitate easy integration into power distribution systems.

Key Features and Benefits:

• High Interrupting Capacity: Supports up to 65 kA at 480V (UL), ensuring resilience against high fault currents.
• Thermal-Magnetic Trip Unit: Provides efficient overload and short-circuit protection for enhanced system safety.

Technical Specifications:

• Amperage: 35Amp
• Poles: 3
• Voltage Rating: 600 Vac max
• Interrupting Ratings: 65 kAIC at 480 Vac (UL), 100 kAIC at 240 Vac (UL), 35 kAIC at 600 Vac (UL/CSA), 22 kAIC at 250 Vdc, 10 kAIC at 690V (IEC)
• Frame Type: PD2 Global
• Trip Unit: Fixed Thermal-Magnetic
• Terminals: Standard line and load

Material Compliance and Certifications:

• Certifications: UL 489, IEC 60947-2, CSA, and CCC marked for assured safety and performance.
• Environmental Compliance: RoHS certified to support eco-conscious operational standards.

Suitability:

• The Eaton PDG23M0035TFFJ is perfect for applications requiring robust three-pole circuit protection in industrial facilities, commercial buildings, and large-scale power systems. It is engineered to perform under high-stress conditions while adhering to global safety and performance benchmarks.
