PDG23M0030TFFL - 30 Amp Circuit Breaker

PDG23M0030TFFL - 30 Amp Circuit Breaker

The Eaton PDG23M0030TFFL is a 30A, 3-pole molded case circuit breaker from the Power Defense line. Built on a Frame 2 platform, it has a fixed trip, load lugs, and a 65kA interrupting rating at 480 VAC. It's a straightforward choice when you need to match an existing breaker or have an application that specifically calls for these electrical ratings. The breaker measures 4.19 inches high, 6 inches wide, and 3.5 inches deep so that you can compare its electrical specs and physical size with your equipment before installation. For maintenance teams, electricians, and facilities working with compatible commercial or industrial electrical systems, the PDG23M0030TFFL provides a practical combination of 30-amp protection, three-pole operation, and high interrupting capacity.

Key Features and Benefits

• 30-amp rating for applications requiring a 30A circuit breaker.
• 3-pole design for compatible three-pole electrical systems.
• Rated 65kA at 480 VAC for high fault-current interruption requirements.
• Part of the Eaton Power Defense molded case circuit breaker family.
• Frame 2 construction.
• Fixed-trip design keeps the trip configuration straightforward.
• Includes load lugs.
• Compact dimensions make it easier to check available installation space.
• Clearly defined ratings simplify replacement and equipment matching.

Technical Specifications

• Manufacturer: Eaton

• Part Number: PDG23M0030TFFL

• Product Type: Molded Case Circuit Breaker (MCCB)

• Product Family: Power Defense

• Frame: Frame 2

• Amperage: 30A

• Poles: 3

• A.I.C. Rating: 65kA at 480 VAC

• Trip: Fixed

• Lugs: Load Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• The PDG23M0030TFFL is identified as an Eaton Global-Rated Power Defense molded-case circuit breaker. Specific certification and material compliance information should be verified against the manufacturer's documentation for this exact part number. If your project requires a particular UL, IEC, RoHS, REACH, or other certification or compliance standard, verify those requirements before installation rather than assuming they apply based on the product family alone.

Where It Works Best

• This breaker is a good fit for commercial and industrial electrical applications that require a 30A, 3-pole molded-case circuit breaker rated at 65kA at 480 VAC. Typical uses may include compatible electrical distribution equipment, machinery, control equipment, maintenance projects, and breaker replacement applications.
• Replacing an existing breaker? Match more than just the amp rating. Check the PDG23M0030TFFL part number, three-pole configuration, Frame 2 size, fixed trip, load lugs, interrupting rating, and physical dimensions against your equipment's requirements.
