PDG23M0025TFFL - 25 Amp Circuit Breaker

PDG23M0025TFFL - 25 Amp Circuit Breaker

When you're replacing a circuit breaker, getting the details right matters. The Eaton PDG23M0025TFFL is a 25A, 3-pole molded case circuit breaker from the Global Rated Power Defense line. This Frame 2 breaker has a fixed trip, load lugs, and a 65kA interrupting rating at 480 VAC. It's a solid choice for compatible commercial and industrial electrical systems where a breaker with these specific ratings is required. The unit measures approximately 4.19 inches high, 6 inches wide, and 3.5 inches deep, so you can compare its electrical specifications and physical size with those of the equipment you're working on. Whether you're replacing an existing PDG23M0025TFFL or matching a breaker to another compatible application, check the full specifications before installation—not just the amperage.

Key Features and Benefits

• 25A rating for applications requiring a 25-amp breaker.
• 3-pole configuration for compatible three-phase electrical systems.
• 65kA A.I.C. at 480 VAC provides the interrupting capacity required for applications with higher available fault current.
• Fixed-trip design keeps the trip configuration straightforward, with no field adjustment of trip settings required.
• Frame 2 construction from the Global Rated Power Defense molded case circuit breaker family.
• Load lugs included for the appropriate load-side connections.
• Compact dimensions of approximately 4.19" H x 6.0" W x 3.5" D.
• Clearly identified as part number PDG23M0025TFFL, making it easier to compare against an existing breaker or equipment specification.

Technical Specifications

• Manufacturer: Eaton

• Part Number: PDG23M0025TFFL

• Type: Molded Case Circuit Breaker

• Product Family: Global Rated Power Defense

• Frame: Frame 2

• Poles: 3

• Amperage: 25A

• A.I.C. Rating: 65kA @ 480 VAC

• Trip: Fixed

• Lugs: Load Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• Specific material compliance information and certification details were not included in the available specifications for the PDG23M0025TFFL. If your project requires a particular listing, approval, or material standard, check the markings on the breaker and the applicable manufacturer documentation for the exact unit before installation. This avoids relying on certification information from a similar breaker that may have a different configuration or rating.

Where It Works Best

• The PDG23M0025TFFL is intended for compatible electrical applications requiring a 25A, 3-pole molded-case circuit breaker with a 65kA rating at 480 VAC. It can be a good fit for commercial or industrial electrical distribution equipment, machinery, and control equipment, as well as maintenance or replacement projects, when the system specifications match.
• Already replacing a PDG23M0025TFFL? Matching the exact part number is a useful starting point. Still, it's worth checking the complete set of ratings before the breaker goes in. Confirm the 25-amp rating, three poles, 65kA @ 480 VAC A.I.C. rating, Frame 2 size, fixed trip, load-lug configuration, and physical dimensions against your equipment requirements.
