PDG23M0025TFFJ - 25Amp Circuit Breaker

PDG23M0025TFFJ - 25Amp Circuit Breaker

The Eaton PDG23M0025TFFJ Power Defense Molded Case Circuit Breaker is designed for precision and reliability, offering advanced protection for three-phase power systems. With a 25Amp rating and an impressive interrupting capacity, this globally rated breaker is a dependable solution for industrial, commercial, and institutional electrical systems. Its compact, durable design and thermomagnetic trip technology ensure performance, safety, and compliance with international standards.

Key Features and Benefits:

• High Fault Protection: Capable of interrupting up to 65kAIC at 480V, ensuring robust protection against overloads and short circuits in high-demand environments.
• Thermomagnetic Trip Technology: Delivers precise fault detection and response to prevent equipment damage and minimize downtime.
• Global Compliance: Certified to UL 489, IEC 60947-2, CSA, and CCC standards, making it suitable for diverse international installations.
• Eco-Friendly Construction: Fully RoHS compliant, supporting sustainable and environmentally responsible installations.

Technical Specifications:

• Amperage Rating: 25Amp
• Voltage Rating: 600V maximum
• Frame Type: PD2 Global, Frame 2
• Interrupting Ratings: 65kAIC @ 480V (UL), 100kAIC @ 240V (UL), 35kAIC @ 600V (UL/CSA), 50kAIC Icu @ 440V (IEC), 22kAIC Icu @ 250 Vdc, 10kAIC Icu @ 690V (IEC)
• Number of Poles: Three-pole
• Terminals: Standard Line and Load
• Dimensions: 88.9 mm (depth) x 152.4 mm (height) x 104.6 mm (width)
• Weight: 1.82 kg

Material Compliance and Certifications:

• Built to meet rigorous international safety standards, the Eaton PDG23M0025TFFJ is certified by UL, IEC, CSA, and CCC. Its RoHS compliance underscores a commitment to reducing environmental impact, aligning with modern sustainability practices.

Suitability:

• Ideal for three-phase applications in commercial buildings, industrial facilities, and data centers, this breaker ensures reliable electrical protection and system integrity. Its compact size and advanced features make it an excellent choice for high-performance power distribution systems.
