When you need a 225A circuit breaker for a commercial or industrial electrical system, getting the ratings and configuration right matters. The Eaton PDG23M0225TFFL is a Power Defense molded case circuit breaker built on Eaton’s Frame 2 platform. It has 3 poles, a 225-amp rating, and a 65kA interrupting rating at 480 VAC. This breaker also uses a fixed thermal-magnetic trip, so there are no electronic trip settings to configure. Standard load-side terminals are included. It’s a practical choice for applications that specifically require this combination of amperage, pole configuration, trip style, and interrupting capacity. For replacement work, it’s always a good idea to compare the full part number and electrical ratings with the existing breaker —not just the amperage rating—to make sure you have the correct match.

Key Features and Benefits

• 225A rating for compatible higher-amperage electrical distribution applications
• 3-pole configuration for use in appropriate three-phase systems
• 65kA interrupting rating at 480 VAC for applications where a higher fault-current rating is required
• Fixed thermal-magnetic trip provides straightforward overcurrent protection without electronic adjustments
• Part of the Eaton Power Defense molded case circuit breaker family
• Frame 2 design for compatible Power Defense applications
• Equipped with standard load-side terminals
• Globally rated design with multiple recognized certifications and standards

Technical Specifications

• Manufacturer: Eaton

• Part Number: PDG23M0225TFFL

• Product Family: Power Defense

• Breaker Type: Molded Case Circuit Breaker (MCCB)

• Frame: Frame 2

• Poles: 3

• Amperage: 225A

• Interrupting Rating: 65kA at 480 VAC

• Trip: Fixed Thermal-Magnetic

• Terminals: Standard Load-Side Terminals

• Height: 6.0 in.

• Width: Approx. 4.12 in.

• Depth: 3.5 in.

• Weight: Approx. 4.01 lb.


Material Compliance and Certifications

• The PDG23M0225TFFL is RoHS-compliant and carries manufacturer-published certifications and standards including UL 489, CSA, IEC 60947-2, and CCC.
• These approvals can be important when a breaker is being matched to equipment with specific regulatory or electrical requirements. The applicable standard should always be checked against the requirements of the equipment and installation.

Where It Works Best

• This 225A 3-pole molded case circuit breaker is a good fit for compatible commercial and industrial electrical distribution systems. Typical applications may include manufacturing facilities, commercial buildings, machinery, electrical distribution equipment, and other three-phase systems that require the specified breaker ratings.
