PDG23M0020TFFJ - 20 Amp Circuit Breaker

PDG23M0020TFFJ - 20 Amp Circuit Breaker

The Eaton PDG23M0020TFFJ is a 20A, 3-pole molded case circuit breaker from the Power Defense line. It's a Frame 2 breaker with a fixed trip and a 65kA interrupting rating at 480 VAC. Line and load lugs are included.

For replacement work, the details are what matter. This breaker measures 4.19 inches high, 6 inches wide, and 3.5 inches deep so that you can compare its size and electrical ratings before installation. The three-pole setup makes it suitable for compatible three-phase applications calling for this configuration.

If you're matching an existing breaker, check more than the amperage. Confirm the PDG23M0020TFFJ part number, Frame 2 configuration, 20A rating, three poles, fixed trip, and 65kA rating at 480 VAC. Those details can save time when you're trying to find the correct breaker for an existing system.

Key Features and Benefits

• 20 amp rating for applications requiring this level of circuit protection
• 3-pole configuration for compatible three-phase systems
• 65kA A.I.C. at 480 VAC
• Fixed trip configuration
• Frame 2 Power Defense design
• Line and load lugs included
• Defined dimensions make it easier to compare against an existing breaker or installation

Technical Specifications

• Manufacturer: Eaton

• Part Number: PDG23M0020TFFJ

• Product Line: Global Rated Power Defense

• Type: Molded Case Circuit Breaker

• Frame: Frame 2

• Poles: 3

• Amperage: 20A

• A.I.C. Rating: 65kA at 480 VAC

• Trip: Fixed

• Lugs: Line and Load

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• Certification and material-compliance requirements can vary by application. For the PDG23M0020TFFJ, confirm any required listings, approvals, or compliance documentation against the manufacturer's current documentation for this exact part number before installation.

Where It Works Best

• This breaker is a good match for commercial and industrial electrical systems that specifically require a 20A, 3-pole MCCB with a 65kA interrupting rating at 480 VAC. It can also make sense for maintenance and replacement projects where an existing Eaton Power Defense breaker needs to be matched by part number and specifications.
• One practical point: don't rely on appearance alone when replacing a circuit breaker. Two breakers may look very similar while having different electrical ratings or configurations. Check the part number, amperage, number of poles, A.I.C. rating, frame, trip type, dimensions, and lug configuration against the equipment requirements before making the replacement.
