PDG23M0200TFFL - 200 Amp Circuit Breaker

PDG23M0200TFFL - 200 Amp Circuit Breaker

The Eaton PDG23M0200TFFL Power Defense Molded Case Circuit Breaker is a globally rated, high-capacity protection solution for industrial and commercial power distribution systems. As part of Eatons Frame 2 series, this three-pole breaker is rated at 200A with a breaking capacity of 65kA at 480V, delivering robust fault protection in demanding environments. With a fixed thermal-magnetic trip unit (Fxd-Fxd) and standard load-only terminals (PDG2X3TA225), it ensures reliable, efficient, and compliant operation in modern power systems.

Key Features and Benefits

• High Fault Tolerance: Breaking capacity of 65kA at 480V (UL) and 35kA at 600V (UL/CSA) ensures reliable performance in critical applications.
• Reliable Thermal-Magnetic Protection: Provides fixed trip settings for overload and short-circuit protection at 200A, ensuring consistent safety and operational reliability.

• Simplified Installation: Equipped with standard load-only terminals for quick and efficient setup, reducing installation time and costs.

Technical Specifications

• Frame Type: Frame 2, Power Defense Series
• Poles: 3-pole
• Amperage Rating: 200A
• Voltage Rating: 600 Vac
• Interrupt Ratings: 65kA @ 480V; 100kA @ 240V; 35kA @ 600V

• Weight: 1.82 kg
• Dimensions: 88.9 mm (L) x 104.6 mm (W) x 152.4 mm (H)

Material Compliance and Certifications

• RoHS Compliant: Reflects Eatons commitment to environmentally sustainable products.
• Certifications: Meets rigorous safety and performance standards globally, ensuring reliable operation in diverse environments.

Suitability

• The Eaton PDG23M0200TFFL is ideal for industrial facilities, commercial buildings, and other high-demand applications. Its high interrupt rating, global compliance, and robust design make it a trusted choice for safeguarding critical electrical systems and infrastructure.

Choose the Eaton PDG23M0200TFFL Circuit Breaker for industry-leading reliability, safety, and efficiency, ensuring optimal performance and protection for your power distribution systems.
