The Eaton PDG23M0175TFFL is a 175-amp, 3-pole molded-case circuit breaker from Eaton's Global Rated Power Defense line. Built on the Frame 2 platform, it has a 65kA interrupting rating at 480 VAC, along with a fixed trip and load lugs. It's a practical choice for commercial and industrial electrical systems that call for this specific combination of amperage, poles, frame size, and interrupting capacity. The breaker measures approximately 4.19 inches high, 6 inches wide, and 3.5 inches deep, so checking the available space and the electrical ratings is important when replacing an existing breaker. If you're trying to match a PDG23M0175TFFL already in service, compare the complete part number and specifications rather than relying on the 175A rating alone.

Key Features and Benefits

• 175-amp rating for applications requiring this level of circuit protection.
• Three-pole design for compatible three-phase electrical systems.
• 65kA interrupting rating at 480 VAC for applications with the corresponding fault-current requirements.
• Fixed trip configuration provides predetermined trip characteristics without field adjustment.
• Frame 2 construction from the Eaton Power Defense molded case circuit breaker family.
• Load lugs included for compatible electrical installations.
• At 4.19" H × 6.0" W × 3.5" D, its dimensions are easy to reference when checking an existing installation or planning a replacement.

Technical Specifications

• Manufacturer: Eaton

• Part Number: PDG23M0175TFFL

• Series: Power Defense

• Type: Molded Case Circuit Breaker

• Frame: Frame 2

• Poles: 3

• Amperage: 175A

• A.I.C. Rating: 65kA at 480 VAC

• Trip: Fixed

• Lugs: Load Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• Specific material-compliance information and certification details were not included in the available specifications for the PDG23M0175TFFL. If your job requires a particular agency listing, certification, or material standard, confirm those requirements against the applicable manufacturer documentation and the markings on the breaker itself.

Where It Works Best

• The PDG23M0175TFFL is intended for compatible commercial and industrial power-distribution applications where a 175A, 3-pole molded case circuit breaker with a 65kA rating at 480 VAC is specified. Depending on the equipment requirements, this may include industrial power distribution, facility electrical systems, machinery, and compatible distribution equipment.

• For replacement work, the part number is especially important. Two breakers can share the same amperage and still have important differences. Before installation, confirm the PDG23M0175TFFL part number, Frame 2 size, three-pole configuration, 175A rating, 65kA at 480 VAC interrupting rating, fixed trip, lug arrangement, dimensions, and compatibility with the equipment being serviced.
