PDG23M0015TFFL - 15Amp Circuit Breaker

PDG23M0015TFFL - 15Amp Circuit Breaker

The Eaton PDG23M0015TFFL Power Defense Molded Case Circuit Breaker delivers world-class electrical protection and performance in demanding industrial and commercial environments. Designed for global compliance, this Frame 2 breaker features a robust three-pole configuration, a 15A rating, and a breaking capacity of 65kA at 480V, ensuring reliable fault protection. With fixed thermal-magnetic trip units and standard load-only terminals, it provides precision and ease of use, making it an ideal solution for modern power distribution systems.

Key Features and Benefits

• High Fault Tolerance: Breaking capacity of 65kA at 480V ensures exceptional protection for high-demand power distribution systems.
• Fixed Thermal-Magnetic Trip Unit: Provides reliable overload and short-circuit protection with consistent settings.
• Ease of Installation: Standard load-only terminals (PDG2X3T100) simplify the installation process, reducing downtime and maintenance costs.

Technical Specifications

• Frame Type: Frame 2, Power Defense Series
• Poles: 3-pole
• Amperage Rating: 15A
• Voltage Rating: 600 Vac max
• Interrupt Ratings: 65kA at 480 Vac;åÊ100kA at 240 Vac;åÊ35kA at 600 Vac

• Weight: 1.82 kg

Material Compliance and Certifications

• RoHS Compliant: Reflects Eaton's commitment to environmentally friendly and sustainable product design.
• Certifications: UL Listed, IEC, CSA, and CCC certifications ensure compliance with global safety and performance standards.

Suitability

• The Eaton PDG23M0015TFFL is ideal for use in industrial facilities, commercial buildings, and other environments where reliable fault protection is critical. Its globally rated specifications make it a versatile solution for systems requiring high performance and compliance with international standards.

With its advanced engineering and high fault tolerance, the Eaton PDG23M0015TFFL Circuit Breaker sets the standard for safety, reliability, and efficiency in modern power distribution systems.
