PDG23M0150TFFL - 150Amp Circuit Breaker

PDG23M0150TFFL - 150Amp Circuit Breaker

The Eaton PDG23M0150TFFL Power Defense Molded Case Circuit Breaker offers industry-leading performance and reliability for industrial and commercial power systems. Designed for global compliance, this Frame 2 breaker features a 150A rating, a breaking capacity of 65 kA at 480V, and a three-pole configuration, making it ideal for protecting critical electrical infrastructure. Equipped with a fixed thermal-magnetic trip unit and standard load-only terminals (PDG2X3TA225), this breaker ensures consistent and efficient protection for modern power distribution systems.

Key Features and Benefits

• High Fault Tolerance: Breaking capacity of 65 kA at 480V (UL) and up to 100 kAIC at 240V (IEC) provides robust protection for demanding environments.
• Fixed Thermal-Magnetic Trip Unit: Delivers precise and consistent overload and short-circuit protection to safeguard equipment and personnel.
• Ease of Installation: Equipped with standard load-only terminals (PDG2X3TA225), simplifying setup and reducing downtime.

Technical Specifications

• Frame Type: Frame 2, Power Defense Series
• Poles: 3-pole
• Amperage Rating: 150A
• Voltage Rating: 600 Vac max
• Interrupt Ratings: 65 kAIC at 480V;åÊ100 kAIC at 240V;åÊ35 kAIC at 600V

• Weight: 1.82 kg
• Dimensions: 88.9 mm x 104.6 mm x 152.4 mm


Material Compliance and Certifications

• RoHS Compliant: Reflects Eaton's commitment to environmentally sustainable manufacturing practices.
• Global Certifications: Meets stringent safety and performance standards for international applications.

Suitability

• The Eaton PDG23M0150TFFL Circuit Breaker is ideal for use in industrial plants, commercial facilities, and data centers that require high fault tolerance and reliable protection. Its robust interrupt capacity and durable construction make it a trusted choice for safeguarding critical electrical systems.

Choose the Eaton PDG23M0150TFFL Circuit Breaker for superior safety, reliability, and efficiency, ensuring the optimal performance of your power distribution systems.
