The Eaton PDG23M0125TFFL is a 3-pole, 125-amp molded case circuit breaker from the Power Defense family. This Frame 2 breaker has a 65kA interrupting rating at 480 VAC and is supplied with a fixed trip and load lugs. It’s a straightforward choice for commercial or industrial electrical equipment that calls for these specific ratings and configuration. The fixed trip keeps things simple—there are no trip settings to adjust in the field. And with three poles, the breaker is suited to compatible three-phase applications. It measures 4.19 inches high, 6 inches wide, and 3.5 inches deep. If you’re replacing an existing breaker, check the complete PDG23M0125TFFL part number and electrical ratings rather than relying on the 125A rating alone. Frame size, poles, interrupting capacity, trip type, and connections all matter when determining whether a breaker is right for the equipment.

Key Features and Benefits

• 125-amp rating for compatible electrical circuits and equipment.
• Three poles for use in compatible three-phase applications.
• Rated 65kA at 480 VAC for applications requiring a higher interrupting capacity.
• Fixed trip design eliminates the need to adjust trip settings in the field.
• Supplied with load lugs.
• Frame 2 Power Defense molded case design.
• Compact dimensions can make it easier to work with where equipment space is limited.

Technical Specifications

• Part Number: PDG23M0125TFFL

• Manufacturer: Eaton

• Product Family: Power Defense

• Breaker Type: Molded Case Circuit Breaker

• Frame: 2

• Poles: 3

• Amperage: 125A

• A.I.C. Rating: 65kA at 480 VAC

• Trip: Fixed

• Connections: Load Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• Power Defense breakers are manufactured for use in electrical distribution applications where recognized safety and performance standards matter. Applicable products within the Power Defense Frame 2 family are associated with standards and certifications including UL 489, CSA, IEC 60947-2, and CCC, as well as RoHS compliance.
• Requirements can differ depending on the exact breaker and installation. When a particular approval or certification is required, confirm it against the product label and manufacturer documentation for the specific unit.

Where It Works Best

• The PDG23M0125TFFL is intended for compatible commercial and industrial electrical distribution applications requiring 125A, three-pole protection. It may be used in electrical distribution equipment, manufacturing facilities, machinery, control equipment, commercial buildings, and other installations that match its electrical and mechanical specifications.

• Its 65kA rating at 480 VAC is an important detail for systems with higher available fault current. For replacement work, carefully compare the existing breaker. The amperage may match while the frame, poles, trip configuration, interrupting rating, or connections do not.
