PDG23M0110TFFL - 110 Amp Circuit Breaker

PDG23M0110TFFL - 110 Amp Circuit Breaker

Need a 110A circuit breaker with three-pole protection and a high interrupting rating? The Eaton PDG23M0110TFFL brings those requirements together in a compact Frame 2 molded case design. It's part of the Global Rated Power Defense family and is rated at 65 kA at 480 VAC, with a fixed trip and load lugs. For electricians, maintenance teams, and facility professionals, that means the key specifications are easy to identify and match to the job at hand.

Size matters when you're working inside existing electrical equipment, too. The PDG23M0110TFFL measures approximately 4.19 inches high, 6 inches wide, and 3.5 inches deep. Whether you're handling a replacement or planning maintenance on compatible distribution equipment, it's worth checking all the details—not just the amperage. Pole count, frame, interrupting rating, trip type, connections, and physical dimensions should all align with the application's requirements.

Key Features and Benefits

• 110A rating for applications requiring 110-amp circuit protection.
• 3-pole configuration for compatible three-phase electrical systems.
• Rated 65kA at 480 VAC, providing substantial interrupting capacity.
• Fixed-trip design provides a defined trip configuration.
• Frame 2 molded case construction.
• Comes with load lugs.
• Measures approximately 4.19" H x 6.0" W x 3.5" D.
• Well suited to commercial and industrial electrical applications where these specifications are required.

Technical Specifications

• Part Number: PDG23M0110TFFL

• Product Type: Molded Case Circuit Breaker

• Product Family: Global Rated Power Defense

• Frame: Frame 2

• Poles: 3

• Amperage: 110A

• A.I.C. Rating: 65kA at 480 VAC

• Trip: Fixed

• Lugs: Load Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• Specific material compliance and certification information was not included in the available specifications for the PDG23M0110TFFL. If your project requires specific listings, approvals, or material compliance standards, check the manufacturer's documentation for the exact part number before installation. Local electrical codes and equipment requirements should also be considered.

Where It Works Best

• The PDG23M0110TFFL makes sense in compatible commercial and industrial electrical distribution systems where a 110A, 3-pole molded case circuit breaker is required. With its 65 kA rating at 480 VAC, fixed trip, and load lugs, it can be a good fit for maintenance, replacement, retrofit, and other electrical distribution applications that require these characteristics.

• Replacing an existing breaker? Don't rely on appearance alone. Two breakers that look similar can have very different electrical characteristics. Check the existing equipment and confirm the part number, 110A rating, three-pole configuration, Frame 2 size, 65kA at 480 VAC rating, fixed trip, load lugs, and dimensions before making a match.
