PDG23G0030TFFL - 30Amp Circuit Breaker

PDG23G0030TFFL - 30Amp Circuit Breaker

The Eaton PDG23G0030TFFL molded case circuit breaker delivers dependable three-pole protection for medium-load applications in industrial, commercial, and residential environments. With a 30Amp current rating and a robust interrupting capacity of 35kA at 480V, this globally certified breaker combines safety, efficiency, and compact design to meet the needs of modern electrical systems.

Key Features and Benefits:

• Exceptional Fault Protection: Rated at 35kAIC at 480V (UL certified) to provide robust fault mitigation in critical systems.
• Three-Pole Configuration: Offers balanced and comprehensive protection across multiple circuits.
• Thermomagnetic Trip Technology: Fixed-fixed trip units (T-M) ensure consistent overcurrent protection with minimal maintenance requirements.
• Eco-Friendly Compliance: Fully RoHS-compliant, making it an environmentally responsible choice.

Technical Specifications:

• Amperage Rating: 30Amp
• Voltage Rating:åÊ600V AC.
• Interrupt Ratings: 65kAIC at 240V and 35kAIC at 480V (UL certified), 55kAIC at 240V and 36kAIC at 380-415V (IEC certified).
• Terminal Type: Standard load-only terminals simplify installation and enhance connection reliability.

Material Compliance and Certifications:

• RoHS Compliance: Manufactured using environmentally friendly materials to support sustainable practices.
• Certifications: Meets UL, IEC, CSA, and CCC standards for global reliability and safety.

Suitability:

• The Eaton PDG23G0030TFFL is ideal for medium-load three-pole applications in commercial buildings, industrial facilities, and residential systems. Its compact design, high interrupt capacity, and global certifications make it the preferred choice for professionals prioritizing safety and efficiency.
