PDG23G0015TFFL - 15 Amp Circuit Breaker

PDG23G0015TFFL - 15 Amp Circuit Breaker

The Eaton PDG23G0015TFFL molded case circuit breaker offers reliable and robust protection for three-pole electrical systems. Designed with a 15Amp current capacity and a 35kA interrupt rating at 480V, it ensures system safety and stability in industrial, commercial, and residential applications. Its globally certified design and compact form factor make it a versatile and dependable choice for modern electrical systems.

Key Features and Benefits:

• High Fault Protection: Rated at 35kA at 480V (UL certified) for effective mitigation of electrical faults in critical systems.
• Three-Pole Configuration: Provides balanced and comprehensive protection for systems requiring three-phase connectivity.
• Thermomagnetic Trip Technology: Features fixed-fixed trip units (T-M) for consistent overcurrent protection and reliable operation.
• Environmentally Conscious: Fully RoHS-compliant, supporting sustainable and eco-friendly installations.

Technical Specifications:

• Amperage Rating: 15Amp
• Voltage Rating:åÊ 600V AC
• Interrupt Ratings: 65kA at 240V and 35kA at 480V (UL certified), 55kA at 240V and 36kA at 380-415V (IEC certified).
• Terminal Type: Standard load-only terminals for quick and secure installation.

Material Compliance and Certifications:

• RoHS Compliance: Designed with environmentally responsible materials for sustainability.
• Certifications: Meets UL, IEC, CSA, and CCC standards for universal trust and reliability.

Suitability:

• The Eaton PDG23G0015TFFL is ideal for low-load three-phase systems in industrial facilities, commercial buildings, and residential installations. Its combination of global certifications, compact design, and reliable performance makes it a trusted choice for engineers and system integrators.
