PDG23G0150TFFL - 150Amp Circuit Breaker

PDG23G0150TFFL - 150Amp Circuit Breaker

Optimize your electrical systems with the Eaton PDG23G0150TFFL Power Defense Molded Case Circuit Breaker, a high-performance solution designed for demanding industrial, commercial, and institutional applications. With a 150Amp current capacity and robust interrupting ratings, this breaker provides dependable protection for complex power distribution systems. Its global certifications and advanced features ensure reliability and versatility for various installations.

Key Features and Benefits:

• High Interrupting Capacity: Offers a fault-clearing capacity of 35kA at 480V, ensuring reliable protection against overcurrent events.
• Durable and Compact Design: Engineered with a space-saving frame while maintaining high durability and performance standards.
• Advanced Trip Technology: Features T-M (Fxd-Fxd) trip units for precise fault detection and quick response, reducing system downtime.
• Sustainability: RoHS-compliant design promotes environmentally responsible installations.

Technical Specifications:

• Amperage Rating: 150Amp
• Voltage Rating: 600V maximum
• Frame Type: PD2 Global, Frame 2
• Interrupting Ratings: 35kA at 480V (UL), 65kA at 240V (UL), 18kA at 600V (UL/CSA), 8kA Icu at 690V (IEC), 55kA Icu at 240V (IEC), 10kA Icu at 125 Vdc
• Dimensions: 88.9 mm (depth) x 152.4 mm (height) x 104.6 mm (width)
• Weight: 1.82 kg

Material Compliance and Certifications:

• Compliance: Built with precision and durability in mind, the Eaton PDG23G0150TFFL meets rigorous safety and environmental standards, ensuring optimal performance.
• Sustainability: Its RoHS compliance aligns with sustainability goals, and certifications from leading organizations affirm its reliability.

Suitability:

• Ideal for high-demand applications in manufacturing facilities, data centers, and commercial buildings, this circuit breaker offers unmatched reliability and fault protection. Its global certifications make it an excellent choice for installations requiring adherence to international standards.
