The Eaton PDG21M0070TFFL is a 70-amp, 1-pole molded-case circuit breaker in the Power Defense family. This particular model uses a Frame 2 design and has a 65kA rating at 277 VAC. It also comes with a fixed trip and load lugs. If you're replacing a breaker that's already in service, the full catalog number is worth checking carefully. A 70A breaker isn't automatically a match just because the amperage is the same. Pole count, frame, interrupting rating, trip setup, lugs, and dimensions all come into play. The PDG21M0070TFFL measures 1.38 inches high, 6 inches wide, and 3.5 inches deep. In short, it's a fairly specific breaker: 70A, one pole, Frame 2, fixed trip, and 65kA at 277 VAC. Those are the numbers you'll want to compare with your equipment's requirements.

Key Features and Benefits

• 70A rating for applications that specify a 70-amp breaker
• 1 pole
• 65kA A.I.C. at 277 VAC
• Eaton Power Defense, Frame 2
• Fixed-trip configuration
• Load lugs
• Dimensions are provided for easier comparison with existing equipment

Technical Specifications

• Manufacturer: Eaton

• Part Number: PDG21M0070TFFL

• Product: Molded Case Circuit Breaker

• Family: Power Defense

• Frame: 2

• Amperage: 70A

• Poles: 1

• A.I.C. Rating: 65kA @ 277 VAC

• Trip: Fixed

• Lugs: Load Lugs

• Height: 1.38"

• Width: 6.0"

• Depth: 3.5"


Material Compliance and Certifications

• The PDG21M0070TFFL is part of Eaton's Global Rated Power Defense molded case circuit breaker line. If a particular certification, agency listing, or material-compliance requirement is important for the job, confirm it using current manufacturer documentation for the exact PDG21M0070TFFL catalog number. It's better to verify the individual breaker than assume that specifications listed for another model in the same family also apply here.

Where It Works Best

• This breaker is a good fit when the equipment calls for a 70A, single-pole Power Defense Frame 2 molded case circuit breaker with a fixed trip, load lugs, and a 65kA interrupting rating at 277 VAC. This can include replacement and maintenance work, as well as compatible electrical distribution applications where these specifications are called for.
• Before swapping out an existing breaker, consider more than just the amperage rating. Check the part number, poles, frame, voltage, A.I.C. rating, trip type, lug arrangement, and dimensions against the equipment requirements. Electrical compatibility should be confirmed by a qualified professional before installation.
