PDG21M0060TFFL - 60Amp Circuit Breaker

PDG21M0060TFFL - 60Amp Circuit Breaker

The Eaton PDG21M0060TFFL is a globally rated, single-pole molded case circuit breaker from the Power Defense series, providing reliable protection for electrical systems with a robust 60Amp current rating. This breaker features a fixed trip unit (T-M) and offers a high interrupting capacity of 65kA at 480V, ensuring exceptional performance in industrial, commercial, and residential applications.

Key Features and Benefits:

• High Fault Protection: Interrupting capacity up to 65kA at 480V (UL) and 100kA at 240V (UL), ensuring dependable system protection.
• Standard Terminals: Equipped with load-only standard terminals for secure and straightforward connections.

Technical Specifications:

• Amperage Rating: 60Amp
• Poles: Single-pole
• Voltage Rating: 600 Vac (maximum)
• Interrupting Capacity: 65kA at 480V (UL), 35kA at 600V (UL/CSA), 100kA at 240V (UL), 70kA Icu at 380-415V (IEC), 50kA Icu at 480V (IEC), 22kA Icu at 250 Vdc
• Dimensions: 3.5 in x 1.38 in x 6 in
• Weight: 2.041 kg

Material Compliance and Certifications:

• Certifications: UL 489, IEC 60947-2, CSA, and CCC
• Environmental Standards: RoHS-compliant, ensuring reduced environmental impact

Suitability:

• The PDG21M0060TFFL is designed for systems that require robust fault protection and is ideal for applications in industrial, commercial, and residential settings. Its compact design and high interrupting capacity make it suitable for environments with space constraints and high safety requirements.
