PDG21M0060TFFJ - 60A Circuit Breaker

PDG21M0060TFFJ - 60A Circuit Breaker

The Eaton PDG21M0060TFFJ Power Defense Molded Case Circuit Breaker is a high-performance, single-pole breaker engineered for superior protection in modern electrical systems. With a robust 60Amp current rating and an exceptional interrupting capacity of 65kA at 480V, this globally rated breaker ensures unmatched reliability for critical applications. Compact and efficient, it is designed to safeguard your systems from overloads and short circuits while meeting international safety standards.

Key Features and Benefits:

• High Interrupting Capacity: Provides up to 65kA at 480V, offering robust protection against high fault currents to maintain system safety and operational continuity.
• Thermomagnetic Trip Technology: Features advanced T-M (Fixed-Fixed) trip units for precise fault detection and rapid response, ensuring minimal downtime.
• Single-Pole Efficiency: Ideal for single-phase systems, delivering reliable protection in a compact, space-saving design.

Technical Specifications:

• Amperage Rating: 60Amp
• Voltage Rating: 600V maximum
• Frame Type: PD2 Global, Frame 2
• Interrupting Ratings: 65kA at 480V (UL), 100kA at 240V (UL/IEC), 35kA at 600V (UL/CSA), 50kA Icu/105kA Icm at 440V (IEC), 22kA at 250 Vdc
• Dimensions: 88.9 mm (depth) x 152.4 mm (height) x 35.1 mm (width)
• Weight: 2.041 kg
• Terminals: Standard Line and Load
• Switch-Off Technique: Thermomagnetic

Material Compliance and Certifications:

• Certifications: Crafted with high-quality materials, the PDG21M0060TFFJ meets rigorous global safety and performance standards.
• RoHS Compliance: Reflects Eaton‰۪s commitment to environmentally responsible manufacturing.
• Standards Compliance: UL, IEC, CSA, and CCC certifications guarantee its reliability across various markets.

Suitability:

• Perfect for single-phase applications, this breaker is ideal for residential, commercial, and industrial settings. Its high interrupting capacity and durable design make it an excellent choice for safeguarding critical electrical systems.
