PDG21M0110TFFL - 110 Amp Circuit Breaker

PDG21M0110TFFL - 110 Amp Circuit Breaker

The Eaton PDG21M0110TFFL is a robust single-pole molded case circuit breaker designed for superior circuit protection in industrial and commercial environments. With a 110Amp rating and an impressive interrupting capacity of 65kA at 480V, it ensures reliable operation even under demanding conditions. The breaker features a compact design with fixed trip unit functionality and standard load-only terminals, making it an ideal choice for diverse electrical systems.

Key Features and Benefits:

• High Fault Protection: Interrupting capacities of 65kA at 480V (UL) and 100kA at 240V (UL) provide exceptional safety and reliability.
• Eco-Conscious Construction: Fully RoHS-compliant for reduced environmental impact.
• Ease of Installation: Equipped with standard load-only terminals for straightforward setup.

Technical Specifications:

• Amperage Rating: 110Amp
• Poles: Single-pole
• Voltage Rating: Up to 600 Vac
• Interrupting Capacity: 65kA at 480V (UL), 100kA at 240V (UL), 35kA at 600V (UL/CSA), 50kA at 480V (IEC), 22kA at 125 Vdc and 250 Vdc, 10kA at 690V (IEC)
• Dimensions: 88.9 mm (L) x 35.1 mm (W) x 152.4 mm (H)
• Weight: 2.041 kg

Material Compliance and Certifications:

• Certifications: UL 489, IEC 60947-2, CSA, CCC
• Environmental Standards: RoHS compliant for safe and sustainable use

Suitability:

• The Eaton PDG21M0110TFFL is perfect for high-performance power systems requiring reliable overcurrent protection. Its versatile and certified design makes it suitable for industrial operations, commercial facilities, and advanced power distribution applications.
