PDG21G0100TFFJ - 100Amp Circuit Breaker

PDG21G0100TFFJ - 100Amp Circuit Breaker

The Eaton PDG21G0100TFFJ Power Defense molded case circuit breaker is a high-performance, globally rated solution designed for modern electrical systems. With a robust 100A current rating and an interrupting capacity of 35kA at 480V, this breaker delivers reliable fault protection in critical applications. Built on Eaton‰۪s advanced Frame 2 architecture, it combines compact design with exceptional durability, making it ideal for installations with space constraints.

Key Features and Benefits:

• High Interrupting Capacity: Rated at 35kA at 480V (UL) and 65kA at 240V (UL), ensuring robust fault protection in demanding systems.
• Compact Frame Design: Eaton‰۪s Frame 2 structure maximizes performance while minimizing space requirements.
• Effortless Installation: Standard line and load terminals allow for quick and straightforward integration.

Technical Specifications:

• Frame Type: PD2 Global, Frame 2
• Amperage: 100A
• Poles: Single Pole
• Voltage Rating: 600 Vac
• Interrupting Capacity:
  • 35kA at 480 Vac (UL)
  • 65kA at 240 Vac (UL)
  • 18kA at 600 Vac (UL/CSA)
  • 36kA Icu at 380-415V (IEC)
• Dimensions: 88.9 mm (L) x 152.4 mm (H) x 35.1 mm (W)
• Weight: 2.041 kg

Material Compliance and Certifications:

• Certifications: UL 489, CSA, IEC 60947-2, CCC Marked
• Compliance: RoHS compliant, ensuring reduced environmental impact.

Suitability:

• The Eaton PDG21G0100TFFJ circuit breaker is ideal for industrial facilities, commercial power systems, and residential applications requiring robust, globally rated circuit protection. Its advanced design and reliable performance make it an excellent choice for mission-critical environments.
