PDG21G0110TFFL - 110 Amp Circuit Breaker

PDG21G0110TFFL - 110 Amp Circuit Breaker

If you're looking for the PDG21G0110TFFL, here are the details that matter. This Eaton Global Rated Power Defense molded-case circuit breaker is a Frame 2, 1-pole breaker rated at 110 amps, with an interrupting rating of 35 kA at 277 VAC. It uses a fixed trip and comes with load lugs, making it a straightforward option for compatible electrical distribution equipment. The breaker measures approximately 1.38 inches high, 6 inches wide, and 3.5 inches deep. For maintenance teams, electricians, and facility professionals replacing an existing breaker, those details are worth checking carefully. Matching the catalog number is a good starting point, but the pole count, amperage, voltage, interrupting rating, trip setup, connections, and physical fit should also line up with the equipment. When your application specifically calls for these ratings, the PDG21G0110TFFL 110A circuit breaker provides a compact, practical solution for circuit protection.

Key Features and Benefits

• 110-amp rating for systems designed to use a 110A breaker.
• Single-pole configuration for compatible applications.
• 35kA interrupting rating at 277 VAC.
• Fixed trip design keeps the protection configuration straightforward.
• Load lugs included as part of the breaker configuration.
• Frame 2 construction from the Global Rated Power Defense family.
• Compact dimensions help when checking the breaker against available equipment space.
• Clearly defined electrical specifications make it easier to determine whether this is the right breaker for an existing application.


Technical Specifications

• Part Number PDG21G0110TFFL

• Product Type Molded Case Circuit Breaker

• Product Family Global Rated Power Defense

• Frame Frame 2

• Poles 1

• Amperage 110A

• A.I.C. Rating & Voltage 35kA @ 277 VAC

• Trip Fixed

• Lugs Load Lugs

• Height 1.38 in.

• Width 6.0 in.

• Depth 3.5 in.


Material Compliance and Certifications

• Specific material compliance information and certification listings were not provided in the available specifications for the PDG21G0110TFFL. If your job requires specific approvals, certifications, or material compliance documentation, check the breaker markings and the manufacturer's current documentation before installation.


Where It Works Best

• The PDG21G0110TFFL makes sense for commercial and industrial electrical applications where the equipment calls for a 1-pole, 110A molded-case circuit breaker with a 35kA rating at 277 VAC. Typical uses may include compatible electrical distribution equipment, panels, machinery, facility electrical systems, and replacement or maintenance work.
• Already have a breaker you're trying to replace? Compare more than the amp rating. Check the PDG21G0110TFFL part number, pole count, frame, voltage, A.I.C. rating, trip type, lug configuration, and dimensions against the existing breaker and equipment requirements. Small differences in specifications can matter when it comes to breaker compatibility.
• Electrical equipment should be selected and installed by qualified personnel in accordance with applicable codes and the requirements of the equipment in which it will be used.
