P250 - 50A Circuit Breaker

P250 - 50A Circuit Breaker

If you're replacing a P250 circuit breaker, the right physical fit and electrical ratings matter most. This new aftermarket P250 50-amp 2-pole circuit breaker was made for that purpose. It is designed to replace the original P250 and fit in the same location as compatible residential electrical equipment. The breaker uses a bolt-on connection and is rated 50 amps, 2-pole, 120/240VAC, with a 10 kA I.C. rating. Overall dimensions are approximately 1.5" high x 2.25" wide x 2.81" deep. It's a straightforward replacement for repair and maintenance jobs where the existing equipment calls for the P250 configuration. Rather than changing the application, the goal here is to match the required form, fit, and function of the existing breaker. It's also built to last for its intended use in compatible legacy residential equipment.

Key Features and Benefits

• Made as an aftermarket replacement for the P250 circuit breaker
• 50-amp rating
• 2-pole configuration
• 120/240VAC voltage rating
• 10 kA I.C. at 120/240VAC
• Bolt-on mounting design

• Useful for maintaining existing residential electrical systems
• Built to last in its intended application

Technical Specifications

• Part Number: P250

• Type: P

• Application: Residential

• Mounting Style: Bolt-On

• Poles: 2

• Amperage: 50A

• Voltage: 120/240VAC

• A.I.C. Rating: 10k @ 120/240VAC

• Dimensions:
  • Height: 1.5 in.
  • Width: 2.25 in.
  • Depth: 2.81 in.
• Product: New Aftermarket Replacement

• Ship Weight: 1.25 lbs.

Material Compliance and Certifications

The available specifications do not include specific material compliance information or third-party certifications for this breaker. Those details should not be assumed. Check the requirements of the existing equipment and applicable electrical codes before installation.

Where It Works Best

The P250 50 amp breaker is intended for compatible residential electrical equipment that requires a Type P, two-pole, bolt-on breaker with the ratings shown above. It can be a useful replacement when repairing or maintaining an older electrical system, especially when the existing breaker location calls for the P250 configuration.
