P130 - 30A Circuit Breaker

P130 - 30A Circuit Breaker

Replacing an older P130 circuit breaker doesn't have to mean changing the existing setup. This new aftermarket P130 replaces the original Pushmatic breaker in compatible residential equipment. It's a 30 amp, single-pole, Type P breaker with a bolt-on connection and a 10kA rating at 120VAC. The breaker measures 1.5" high, 1" wide, and 2.81" deep, so it's made around the size and fit required for an existing P130 location. For electricians, maintenance professionals, and property owners working with older electrical equipment, that familiar fit is often the most important part of finding the right replacement. If you're replacing a P130 breaker, compare the ratings, dimensions, and mounting style to ensure everything matches your application. This replacement is built to last and is designed to do one thing: provide the correct form, fit, and function for compatible P130 installations.

Key Features and Benefits

• Made as an aftermarket replacement for the original P130 breaker
• 30 amp rating
• 1-pole configuration
• Type P design
• Bolt-on mounting
• Rated 10kA at 120VAC
• Sized to fit compatible existing P130 locations
• A useful replacement option when maintaining older residential electrical equipment
• Built to last when used within its intended application and ratings

Technical Specifications

• Part Number: P130

• Type: P

• Application: Residential Circuit Breaker

• Poles: 1

• Amperage: 30A

• A.I.C. Rating: 10kA

• Voltage: 120VAC

• Mounting: Bolt-On

• Dimensions:
  • Height: 1.5 in.
  • Width: 1.0 in.
  • Depth: 2.81 in.
• Product Status: New Aftermarket Replacement

• Ship Weight: 0.50 lbs.

Material Compliance and Certifications

Specific certification, listing, and material compliance information has not been provided for this breaker. Requirements vary by equipment and installation location, so don't assume a particular approval or certification applies. Check the breaker markings and confirm any required electrical codes, equipment requirements, or local approvals before installation.

Where It Works Best

This P130 30 amp breaker is meant for existing residential electrical equipment that uses the corresponding Type P bolt-on configuration. In other words, it's for applications where you need to maintain the original P130 size, mounting arrangement, and electrical ratings.
