NEJ233225 - 225Amp Circuit Breaker

NEJ233225 - 225 Amp Circuit Breaker

The NEJ233225 is a 225 amp, 3 pole molded case circuit breaker used in commercial and industrial three-phase systems. It provides thermal magnetic protection, meaning it reacts to both long-term overloads and sudden short circuits to help protect wiring and connected equipment. With a 10kA interrupting rating at 240VAC, it’s suited for panelboards and distribution equipment where a 225A breaker is required. The bolt-on design gives you a solid, secure connection to the panel, and the load-side lugs make terminations straightforward for electricians handling installs or replacements. This breaker is typically used as a replacement in existing NEJ frame setups or during maintenance projects where matching specifications matter. It’s built for consistent, everyday performance in environments operating up to 40°C.

Key Features and Benefits

• 225 amp rating
• 3 poles for three-phase systems
• Thermal magnetic trip protection
• 10kA @ 240VAC interrupting capacity
• Bolt-on mounting style
• Load-side lug terminals

Technical Specifications

• Model: NEJ233225

• Amps: 225A

• Poles: 3

• Voltage Rating: 240VAC

• AIC Rating: 10kA @ 240VAC

• Frame: NEJ

• Trip Type: Thermal Magnetic

• Mounting: Bolt-On

• Dimensions: 4.13" W x 7.00" L x 3.38" D

• Weight: 9 lbs

• Operating Temperature: Up to 40°C


Material Compliance and Certifications

• The NEJ233225 is manufactured to meet established industry safety and performance standards for molded case circuit breakers. It is built from quality materials intended for use in commercial and industrial electrical systems within its rated limits.

Where It Works Best

• You’ll typically find this breaker in commercial buildings, light industrial facilities, and other three-phase distribution panels that call for a 225 amp NEJ frame breaker. It’s a practical solution for maintenance teams and electrical contractors replacing an existing breaker with matching ratings and bolt-on configuration.
