NEB3B060B - 60Amp Circuit Breaker

NEB3B060B - 60Amp Circuit Breaker

Elevate your electrical safety standards with the Siemens NEB3B060B circuit breaker. Engineered for reliability and efficiency, this low voltage panelboard mount breaker features an EG frame with a thermal-magnetic trip unit, ensuring optimal protection for your electrical systems. Rated at 60 amps, this 3-pole breaker boasts a breaking capacity of 22kAIC at 600Y/347V and 35kAIC at 480V, making it suitable for a variety of commercial applications.

Key Features and Benefits:

• Reliable Performance: Equipped with a thermal-magnetic trip unit, the NEB3B060B ensures fast response to overcurrent conditions, protecting your electrical system from potential hazards.
• High Breaking Capacity: With a robust breaking capacity of 22kAIC at 600Y/347V, this breaker effectively handles high fault currents, enhancing system safety.
• Versatile Wiring Options: Featuring load-side lugs only (TA1EG10), this breaker supports a wire range of 8 to 1/0 AWG (CU/AL), offering flexibility for various installation requirements.

Technical Specifications:

• Amperage: 60A
• Poles: 3
• Voltage: 600Y/347V, 480V
• Dimensions (W x H x D): 3 x 5.5 x 3 inches
• Weight: 2.646 lbs
• Breaking Capacity: 22kAIC at 600Y/347V, 35kAIC at 480V

Material Compliance and Certifications:

• The NEB3B060B circuit breaker is UL listed, ensuring it meets rigorous safety and performance standards. While detailed RoHS compliance information is unavailable, users are encouraged to verify suitability for specific applications.

Suitability:

• Ideal for commercial panelboard applications, the NEB3B060B is designed for robust protection in low voltage environments. Whether you‰۪re upgrading existing systems or planning new installations, this Siemens breaker delivers dependable performance and compliance with industry standards.
