NEB3B035B - 35Amp Circuit Breaker

NEB3B035B - 35Amp Circuit Breaker

When you're replacing a breaker in an existing panelboard, getting the details right matters. The NEB3B035B is a 35-amp, 3-pole molded case circuit breaker designed for compatible Type NEB panelboard applications. It is rated 35 kA.I.C. at 480VAC and 85 kA.I.C. at 240VAC, with a 40°C rating and HACR designation. The breaker measures about 5.5 inches high, 3 inches wide, and 3 inches deep, and includes load-side terminals.

Key Features and Benefits

• 35-amp, 3-pole design for compatible three-pole applications
• Type NEB molded case construction for systems requiring this breaker configuration
• Panelboard mount for compatible existing installations
• HACR rated for applicable heating, air-conditioning, and refrigeration equipment
• 40°C rated
• Load-side terminals included

Technical Specifications

• Part Number: NEB3B035B

• Breaker Type: Molded Case Circuit Breaker

• Type: NEB

• Amperage: 35 Amps

• Poles: 3

• A.I.C. Rating: 35k @ 480VAC; 85k @ 240VAC

• Mounting: Panelboard Mount

• Temperature Rating: 40°C

• HACR Rated: Yes

• Load-Side Terminals: Included

• Height: 5.5 in.

• Width: 3.0 in.

• Depth: 3.0 in.

• Ship Weight: 6.00 lbs.


Material Compliance and Certifications

The NEB3B035B is specified as HACR-rated and carries a 40°C rating. This makes the HACR designation relevant when the breaker is used with compatible heating, air-conditioning, or refrigeration equipment that requires it.

No other material-compliance certifications are identified in the supplied specifications. If your installation requires a specific approval or compliance standard, check the breaker nameplate and the panelboard or equipment documentation before installation.

Where It Works Best

The NEB3B035B 35 amp circuit breaker is intended for compatible panelboards and existing electrical systems that require its Type NEB configuration. It's especially relevant for maintenance and replacement work where the objective is simple: match the breaker the system was designed to use.

You'll typically want to consider this breaker when working with compatible commercial or industrial electrical distribution equipment, HVAC applications, panelboards, and existing three-phase systems.
