NEB3B030B - 30Amp Circuit Breaker

NEB3B030B - 30Amp Circuit Breaker

Finding the right breaker for your existing panelboard often comes down to the details. The NEB3B030B is a 30-amp, 3-pole molded-case circuit breaker made for compatible Type NEB panelboard applications. It has an interrupting rating of 35 kAIC at 480VAC and 85 kAIC at 240VAC, a 40°C rating, and an HACR rating.

Key Features and Benefits

• 30-amp rating for applications designed around this current rating.
• 3-pole configuration for compatible three-pole electrical systems.
• Type NEB design for equipment that requires this breaker configuration.
• Rated 35 kA icu at 480VAC and 85 kA icu at 240VAC.
• Panelboard-mount design for compatible installations.
• HACR rated for applications that require this rating, with all other specifications matching.
• 40°C rating for its specified operating conditions.
• Load-side terminals included, an important detail when matching existing equipment.

Technical Specifications

• Part Number: NEB3B030B

• Type: NEB

• Breaker Type: Molded Case Circuit Breaker

• Amperage: 30A

• Poles: 3

• AIC Rating: 35k @ 480VAC; 85k @ 240VAC

• Temperature Rating: 40°C

• HACR Rated: Yes

• Mounting: Panelboard Mount

• Height: 5.5 in.

• Width: 3.0 in.

• Depth: 3.0 in.

• Terminals: Load-Side Terminals Included

• Ship Weight: 6.00 lbs.


Material Compliance and Certifications

The NEB3B030B is HACR-rated and rated for 40 °C. The available specifications identify no other material-compliance certifications or agency listings, so do not assume them.

When using this breaker as a replacement, check more than the amperage alone. Confirm the part number, number of poles, voltage and interrupting ratings, dimensions, mounting arrangement, and the requirements of the panelboard or other equipment before installation.

Where It Works Best

The NEB3B030B circuit breaker is best suited to existing electrical systems and panelboards designed for the Type NEB configuration. It's a practical choice for maintenance and replacement work where matching the original breaker's specifications and physical fit is important.

You may also use this breaker in compatible heating, air-conditioning, and refrigeration applications that call for an HACR-rated breaker, provided the rest of the electrical specifications match the equipment.
