NEB3B020B - 20Amp Circuit Breaker

NEB3B020B - 20Amp Circuit Breaker

Introducing the Siemens NEB3B020B, a top-performing low voltage panelboard mount circuit breaker designed to ensure reliable and efficient electrical protection in commercial and industrial environments. This EG frame circuit breaker features a thermal-magnetic trip unit, providing robust overcurrent protection. Engineered with a standard breaking capacity, the NEB3B020B ensures safety and reliability under demanding conditions. Rated at 20A, this three-pole circuit breaker offers an impressive interrupting capacity of 22KAIC at 600Y/347V and 35KAIC at 480V, making it a versatile and dependable choice for a wide range of applications.

Key Features and Benefits:

• Thermal-Magnetic Trip Unit: Ensures precise and reliable overcurrent protection, safeguarding your electrical systems from overloads and short circuits.
• High Interrupting Capacity: With an interrupting capacity of 22KAIC at 600Y/347V and 35KAIC at 480V, this circuit breaker effectively handles high-fault conditions.
• Load Side Lugs: Equipped with load side lugs (TA1EG10) with a wire range of 8 - 1/0 AWG (CU/AL), providing secure and reliable connections.

Technical Specifications:

• Amperage Rating: 20A
• Voltage Rating: 600Y/347V and 480V
• Interrupting Rating: 22KAIC at 600Y/347V, 35KAIC at 480V
• Trip Type: Thermal-Magnetic
• Frame Type: EG
• Dimensions: 3 in (Width) x 5.5 in (Height) x 3 in (Depth)
• Weight: 1.257 lb
• Special Features: Load side lugs only (TA1EG10), Wire range: 8 - 1/0 AWG (CU/AL)

Material Compliance and Certifications:

• The Siemens NEB3B020B is manufactured to meet the highest industry standards, ensuring reliability and safety. It is UL listed, complying with rigorous safety regulations for electrical protection devices. Additionally, it adheres to the WEEE (2012/19/EU) Take-Back Obligation, ensuring environmentally responsible disposal.

Suitability:

• The Siemens NEB3B020B circuit breaker is ideally suited for a variety of low voltage panelboard applications in commercial and industrial settings. Its high interrupting capacity and advanced protection features make it a reliable choice for protecting electrical systems against overcurrent conditions, ensuring uninterrupted operation and enhanced safety.
