FEDERAL PACIFIC
NE231020 - 20Amp Circuit Breaker
NE231020 - 20Amp Circuit Breaker
Couldn't load pickup availability
NE231020 - 20 Amp Circuit Breaker
The NE231020 is a 20-amp, 3-pole Type NE molded-case circuit breaker with a bolt-on connection and thermal-magnetic trip. It is rated 10k AIC at 240VAC and measures 6.19 inches high, 4.13 inches wide, and 3.38 inches deep. This breaker is primarily used when servicing existing electrical equipment that requires this particular Type NE configuration. If you're replacing an older breaker, compare the part number, ratings, number of poles, mounting style, and dimensions with what's already installed. You can also find the NE231020 under the numbers NE233020, NE235020, and NE237020, which is useful when checking older equipment records or identifying a replacement. With its molded case construction and thermal-magnetic operation, this breaker is built to last and is intended to provide overload and short-circuit protection in compatible applications.
Key Features and Benefits
- 20-amp, 3-pole breaker for compatible Type NE applications
- 10k AIC at 240VAC rating
- Thermal-magnetic trip for overload and short-circuit protection
- Bolt-on connection for equipment designed around this mounting style
- Molded case construction
- Useful for maintaining compatible legacy electrical equipment
- Also identified as NE233020, NE235020, and NE237020
- Built to last when properly installed and used within its rated specifications
Technical Specifications
-
Part Number: NE231020
-
Alternate Part Numbers: NE233020, NE235020, NE237020
-
Type: NE
-
Breaker Type: Molded Case Circuit Breaker
-
Connection: Bolt-On
-
Trip: Thermal-Magnetic
-
Poles: 3
-
Amperage: 20 Amps
- AIC / Voltage: 10k @ 240VAC
- Ship Weight: 6.00 lbs.
-
Dimensions:
- Height: 6.19 in.
- Width: 4.13 in.
- Depth: 3.38 in.
Material Compliance and Certifications
- Specific material compliance information, agency listings, and certifications were not provided for this breaker. If your application requires a particular certification or compliance standard, check the markings on the breaker and the available equipment documentation before installation.
- Requirements vary by application, so verify the breaker against the equipment specifications and any electrical codes that apply to the installation.
Where It Works Best
- The NE231020 is best suited for existing equipment that calls for a 20 amp, 3-pole Type NE bolt-on circuit breaker with a 10k AIC rating at 240VAC. This is especially important when repairing or maintaining older electrical equipment, where the correct breaker style and ratings matter.
- When you're matching a replacement, don't go by the 20 amp rating alone. Check the breaker that's coming out of the equipment. Make sure the three-pole arrangement, Type NE configuration, bolt-on connection, voltage and AIC rating, and physical size match the application requirements.
- You may also run across NE233020, NE235020, or NE237020 while checking paperwork or identifying an existing breaker. Those alternate numbers can help when cross-referencing NE231020.
