FEDERAL PACIFIC

NC0230 - 30Amp Circuit Breaker

NC0230 - 30Amp Circuit Breaker

Regular price $85.00 USD
Regular price Sale price $85.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

NC0230 - 30Amp Circuit Breaker

When you're replacing a breaker in older electrical equipment, getting the right fit matters as much as matching the electrical ratings; the NC0230 is a 30-amp, 2-pole Type NC circuit breaker for applications that use this specific compact Stab-On configuration.

It measures just 1 inch wide, with an overall size of 3.38" high x 1.0" wide x 2.31" deep. Electrically, it is rated 120/240VAC with a 10 kA.I.C. and uses a thermal magnetic trip mechanism for overcurrent protection.

Our New NC0230 offering is a newly manufactured aftermarket replacement designed to fit the existing NC0230 location. This makes it a straightforward option when you're working on compatible legacy equipment and need to keep the original breaker arrangement intact.

Simply put, if your equipment calls for an NC0230, this breaker provides the correct amperage, pole configuration, Stab-On connection, and physical footprint in a replacement built to last.

Key Features and Benefits

  • 30 amp, 2-pole configuration for compatible NC0230 applications
  • 120/240VAC operating voltage
  • 10 kA.I.C. rating at 120/240VAC
  • Thermal-magnetic trip for overcurrent protection
  • Stab-On design for the required connection style
  • Compact 1-inch width helps maintain the existing space-saving configuration
  • Designed as a form, fit, and functional replacement for the NC0230
  • Newly manufactured aftermarket option for customers selecting New condition
  • Built to last when properly installed and used within its specified ratings

Technical Specifications

  • Part Number: NC0230
  • Type: NC
  • Amperage: 30 Amps
  • Poles: 2
  • Voltage: 120/240VAC
  • A.I.C. Rating: 10k @ 120/240VAC
  • Trip Mechanism: Thermal Magnetic
  • Connection: Stab-On
  • Height: 3.38 in.
  • Width: 1.0 in.
  • Depth: 2.31 in.
  • Ship Weight: 1.75 lbs.

Material Compliance and Certifications

The specifications provided for this breaker do not include certification or material-compliance details, so we don't make assumptions about UL, CSA, RoHS, or other certifications.

If your installation requires a particular listing or certification, confirm those requirements before selecting the breaker.

Where It Works Best

The NC0230 breaker is intended for compatible legacy electrical equipment that requires this Type NC configuration. It's especially useful for maintenance and replacement work when you need to retain the existing Stab-On connection, 30-amp rating, two-pole arrangement, and compact 1-inch footprint.

Before replacing a breaker, check the existing part number and verify the amperage, voltage, poles, connection style, dimensions, and equipment requirements. Qualified electrical personnel should install it in accordance with applicable electrical codes.
