FEDERAL PACIFIC
NC0220 - 20Amp Circuit Breaker
NC0220 - 20Amp Circuit Breaker
Couldn't load pickup availability
NC0220 - 20Amp Circuit Breaker
Replacing an NC0220 circuit breaker in existing equipment? This 20 amp, 2-pole Type NC breaker matches the form, fit, and function needed for compatible NC0220 applications. It has a compact, stab-on design measuring 3.38 inches high, 1 inch wide, and 2.31 inches deep, so it fits the existing location without requiring unnecessary changes to the equipment layout. The breaker is rated 10 kA.I.C. at 120/240VAC and uses thermal-magnetic trip operation for overcurrent protection. If you choose New condition, you'll receive a newly manufactured aftermarket replacement made specifically to fit and replace the NC0220 in compatible equipment. It's a straightforward solution for keeping an existing electrical system in service when the application calls for the NC0220 configuration. Simply put, this breaker delivers the right fit, ratings, and configuration—and it's built to last.
Key Features and Benefits
- 20 amp, 2-pole configuration for compatible NC0220 applications.
- Stab-on connection matches the intended mounting configuration.
- Space-saving design with a compact 1-inch width.
- Thermal magnetic trip operation provides overcurrent protection.
- Rated 10 kA.I.C. at 120/240VAC.
- Designed as a form-, fit-, and function replacement for the NC0220.
- The New option is a newly manufactured aftermarket replacement made specifically for the existing NC0220 location.
- Built to last for its intended application.
Technical Specifications
-
Part Number: NC0220
-
Type: NC
-
Amperage: 20 Amps
-
Poles: 2
-
Voltage: 120/240VAC
-
A.I.C. Rating: 10k
-
Trip Type: Thermal Magnetic
-
Mounting / Connection: Stab-On
-
Height: 3.38 in.
-
Width: 1.0 in.
-
Depth: 2.31 in.
- Ship Weight: 1.75 lbs.
-
Design: Space-Saving
Material Compliance and Certifications
The available product specifications include no specific material compliance declarations or third-party certifications. For that reason, do not assume UL, CSA, RoHS, or other certification claims. Check the markings and documentation supplied with the specific breaker when the application requires certification or compliance information.
Where It Works Best
The NC0220 20 amp circuit breaker is intended for compatible legacy electrical equipment that requires this specific Type NC configuration, two-pole design, stab-on connection, physical footprint, and 120/240VAC rating. It's a particularly useful choice when you're replacing an existing NC0220 and want to maintain the established breaker position and equipment layout.
As with any circuit breaker replacement, matching the physical dimensions is only part of the job. Confirm the electrical ratings, configuration, and equipment requirements before installation. A qualified electrical professional should handle installation in accordance with applicable electrical codes and equipment requirements.
