FEDERAL PACIFIC
NC0215 - 15Amp Circuit Breaker
NC0215 - 15Amp Circuit Breaker
Couldn't load pickup availability
NC0215 - 15Amp Circuit Breaker
The NC0215 is a 15-amp, 2-pole Type NC circuit breaker used in electrical equipment designed for this specific stab-on configuration. It has a compact, space-saving design and measures 3.38" high x 1" wide x 2.31" deep. This breaker is rated 10 kA.I.C. at 120/240VAC and uses thermal-magnetic trip operation. If you're replacing an existing NC0215, the New option is a newly manufactured aftermarket breaker made to fit the same location. It's intended as a form, fit, and functional replacement, which is especially important when you're working on older equipment where the breaker style and available space are already fixed. Before replacing a breaker, check more than the amperage. The pole count, voltage, A.I.C. rating, connection style, dimensions, and equipment requirements must all match. For an existing NC0215 application, those details matter.
Key Features and Benefits
- 15-amp, 2-pole breaker
- Type NC configuration
- Stab-on connection
- Thermal-magnetic trip
- 10 kA.I.C. at 120/240VAC
- Compact 1-inch width
- Space-saving design
- Made for existing NC0215 applications
- New aftermarket replacement available
- Built to last in its intended application
Technical Specifications
-
Part Number: NC0215
-
Type: NC
-
Amperage: 15A
-
Poles: 2
-
Voltage: 120/240VAC
-
A.I.C. Rating: 10k @ 120/240VAC
-
Trip Type: Thermal Magnetic
-
Connection: Stab-On
-
Height: 3.38 in.
-
Width: 1.00 in.
-
Depth: 2.31 in.
- Ship Weight: 1.75 lbs.
-
Design: Space-Saving
Material Compliance and Certifications
Material compliance and certification information was not included in the specifications provided. If you need a specific listing, certification, or material requirement for the job, confirm it in the documentation supplied with the breaker before installation.
Where It Works Best
The NC0215 is meant for existing equipment that uses the Type NC, 2-pole stab-on configuration. It's a good fit for replacement and maintenance work when the original breaker location must remain as-is.
For the New option, the aftermarket replacement is made specifically to fit the existing NC0215 location. Always confirm the 15A rating, 2-pole configuration, 120/240VAC rating, 10k A.I.C., connection style, and dimensions against the equipment requirements before installation.
