FEDERAL PACIFIC

NBGF30 - 30Amp Circuit Breaker

NBGF30 - 30Amp Circuit Breaker

Regular price $0.00 USD
Regular price Sale price $0.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

NBGF30 - 30Amp Circuit Breaker

The NBGF30 is a 30-amp, single-pole thermal-magnetic circuit breaker with a bolt-on connection. It is rated 10 kAIC at 120VAC and measures 3.5" high x 1" wide x 2.31" deep. If you're replacing a breaker in existing equipment, the details matter. The NBGF30 is intended for applications that call for this specific NBGF configuration, including the same mounting style, amperage, voltage, pole count, and interrupting rating. Its bolt-on design also makes it important to confirm the mounting arrangement before installation. For older electrical systems where the goal is to keep the original setup in place, the NBGF30 provides the form, fit, and function needed for a properly matched replacement. It's a straightforward electrical component that's built to last when used in the application it was designed for.

Key Features and Benefits

  • 30 amp, 1-pole configuration
  • Bolt-on mounting
  • Thermal magnetic operation
  • Rated for 120VAC
  • 10k AIC at 120VAC
  • Compact 3.5" x 1" x 2.31" dimensions
  • Suitable for compatible legacy electrical equipment
  • Helps maintain the original equipment configuration when specifications match

Technical Specifications

  • Part Number: NBGF30
  • Type: NBGF
  • Amperage: 30A
  • Poles: 1
  • Voltage: 120VAC
  • A.I.C. Rating: 10k @ 120VAC
  • Operation: Thermal Magnetic
  • Mounting: Bolt-On
  • Height: 3.5 in.
  • Width: 1.0 in.
  • Depth: 2.31 in.
  • Ship Weight: 2.10 lbs.

Material Compliance and Certifications

Specific material compliance and certification information was not provided with the available NBGF30 specifications. Check the markings on the breaker and the applicable product documentation when you need to confirm a particular certification or compliance requirement.

Where It Works Best

The NBGF30 is best suited for compatible legacy electrical equipment that requires a 30-amp, 1-pole NBGF bolt-on breaker rated 10k AIC at 120VAC. It's particularly useful for maintenance and replacement work where the existing electrical equipment will remain in service.

Before installing a replacement, check the existing breaker's full specifications. The NBGF type, bolt-on connection, 30A rating, single-pole configuration, voltage, AIC rating, and physical dimensions should match the equipment requirements.
