FEDERAL PACIFIC
NBGF15 - 15Amp Circuit Breaker
NBGF15 - 15Amp Circuit Breaker
Couldn't load pickup availability
NBGF15 - 15Amp Circuit Breaker
When you're replacing a breaker in an existing electrical system, getting the details right matters. The NBGF15 circuit breaker is a 15-amp, 1-pole thermal magnetic breaker with a bolt-on design. It is rated for 120VAC and 10 kA IC and measures 3.5 inches high, 1 inch wide, and 2.31 inches deep. Those specifications make the NBGF15 a practical option for compatible legacy equipment where you need to match the existing breaker's type, electrical ratings, mounting style, and physical fit. Don't overcomplicate the selection: compare the NBGF15 specifications with the breaker you're replacing and the equipment's requirements. If the ratings and configuration match, this breaker can help keep an existing system operating with the form and function it was designed around. It's a straightforward electrical component built to last when selected and installed correctly.
Key Features and Benefits
- 15 amp, single-pole design for applications requiring this specific configuration.
- Bolt-on mounting for equipment designed to accept an NBGF bolt-on breaker.
- Thermal-magnetic operation provides the breaker's overload and overcurrent trip functions.
- Rated for 120VAC with a 10k AIC rating.
- Compact 3.5" x 1" x 2.31" dimensions make it easier to compare physical fit with the existing breaker.
- A useful option for compatible legacy electrical equipment where matching the original specifications is important.
- Built to last and intended for continued service in the proper application.
Technical Specifications
-
Part Number: NBGF15
-
Type: NBGF
-
Breaker Type: Thermal Magnetic
-
Mounting: Bolt-On
-
Poles: 1
-
Amperage: 15A
-
Voltage: 120VAC
-
A.I.C. Rating: 10k @ 120VAC
-
Height: 3.5 in.
-
Width: 1.0 in.
-
Depth: 2.31 in.
Material Compliance and Certifications
Material composition and specific certification or agency-listing information were not included in the available specifications for the NBGF15. Because requirements can vary by installation, don't assume UL, CSA, RoHS, or other compliance based on the part number alone. Check the breaker markings and the applicable equipment documentation when a particular certification is required.
Where It Works Best
The NBGF15 15 amp circuit breaker makes the most sense in existing electrical equipment designed for an NBGF-type, 1-pole, bolt-on thermal magnetic breaker with the same ratings. This is especially relevant when maintaining a legacy system and the goal is to match the existing breaker's form, fit, and function.
Before installation, compare more than just the amperage. Check the NBGF type, 1-pole configuration, bolt-on mounting, 15A rating, 120VAC rating, 10k AIC rating, and physical dimensions against the equipment requirements. A qualified electrical professional should confirm final compatibility and installation.
