FEDERAL PACIFIC
NAGF20 - 20Amp Circuit Breaker
NAGF20 - 20Amp Circuit Breaker
Couldn't load pickup availability
NAGF20 - 20Amp Circuit Breaker
Replacing a breaker in older equipment? The small details matter. NAGF20 is a 20-amp, 1-pole thermal-magnetic circuit breaker for compatible equipment using the Type NAGF stab-on configuration. It carries a 120VAC rating and 10 kAIC. This breaker measures 3.5 inches high, 1 inch wide, and 2.31 inches deep. That makes checking the existing breaker especially important. Before replacing it, compare the part type, dimensions, amperage, voltage, pole count, and connection. A 20-amp rating by itself doesn't tell the whole story. For maintenance and repair work, the NAGF20 is a sensible choice when the equipment calls for this particular configuration. The goal is simple: match the original form, fit, and function as closely as possible. It's built to last in its intended application without making claims beyond the breaker's stated ratings.
Key Features and Benefits
- 20-amp rating with a single-pole configuration
- Rated for 120VAC
- 10k AIC at 120VAC
- Thermal magnetic breaker design
- Type NAGF stab-on connection
- 1-inch-wide body
- Suitable for compatible legacy equipment
- Useful when the original form, fit, and function need to be maintained
Technical Specifications
-
Part Number: NAGF20
-
Type: NAGF
-
Amperage: 20A
-
Poles: 1
-
Voltage: 120VAC
-
AIC Rating: 10k @ 120VAC
-
Operation: Thermal Magnetic
-
Connection: Stab-On
- Ship Weight: 2.0 lbs.
-
Dimensions:
- Height: 3.5 in
- Width: 1.0 in
- Depth: 2.31 in
Material Compliance and Certifications
Specific certification and material-compliance information wasn't provided with the available NAGF20 specifications, so it wouldn't be appropriate to add or assume those details. If a job requires a particular certification or compliance standard, check the breaker markings and the applicable product documentation.
Where It Works Best
The NAGF20 is best suited to existing electrical equipment designed to accept a Type NAGF stab-on circuit breaker. It's particularly relevant for maintenance or repair work where the required breaker is 20A, 1-pole, 120VAC, and 10k AIC.
