NA50 - 50Amp Circuit Breaker

NA50 - 50Amp Circuit Breaker

If you need a dependable 50 amp single-pole circuit breaker for a compatible Stab-Lok panel, the Schneider Electric NA50 is built to handle the job. Rated for 120V AC systems, this breaker helps protect branch circuits from overloads and short circuits before damage can occur. With a 10 kA interrupting rating, it’s designed to safely stop higher fault currents that can happen in residential and light commercial environments. The plug-in Stab-Lok style makes installation straightforward, while the solid screw terminal connections support both copper and aluminum conductors for flexible wiring setups.

Key Features and Benefits

• 50 Amp Rating: Ideal for higher-load 120V branch circuits.
• Single-Pole Design (1P): Designed for standard 120V applications.
• 10 kA Interrupting Capacity: Helps protect equipment during short-circuit conditions.
• Stab-Lok Plug-In Mounting: Snaps securely into compatible panelboards.
• Wide Wire Range: Accepts AWG 14 to AWG 2 copper or aluminum conductors.
• Space-Saving Size: Compact footprint fits standard breaker spaces.


Technical Specifications

• Manufacturer: Schneider Electric

• Model Number: NA50

• Amperage: 50 Amp

• Voltage: 120V AC

• Poles: 1

• Interrupting Rating: 10,000 A (10 kA)

• Mounting Type: Plug-In (Stab-Lok)

• Terminal Type: Screw Terminal

• Wire Size Range: AWG 14 – AWG 2 (Cu/Al)

• Dimensions: 3.00" H x 1.00" W x 3.50" L

• Weight: 5.12 oz


Material Compliance and Certifications

• CSA Certified: This breaker is CSA certified, confirming it meets recognized safety requirements.
• Green Premium and RoHS Compliance: It also carries Schneider Electric’s Green Premium designation and complies with RoHS standards, supporting environmental responsibility and material transparency.


Where It Works Best

• The NA50 50A breaker is commonly used in residential and light commercial electrical panels that require single-pole, 120V circuit protection. It’s a practical choice for replacing an existing compatible Stab-Lok breaker or maintaining an existing panel configuration. When properly matched to the panel and application, it delivers steady, reliable circuit protection to help keep electrical systems operating safely.
