FEDERAL PACIFIC

NA30 - 30Amp Circuit Breaker

NA30 - 30Amp Circuit Breaker

Regular price $36.00 USD
Regular price Sale price $36.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

NA30 - 30Amp Circuit Breaker

Need an NA30 circuit breaker for an existing application? This 30 amp, single-pole breaker is designed for installations that require the familiar Type NA configuration. It uses a Stab-On connection, features a thermal-magnetic design, and is rated 10 kA at 120VAC.

For the New condition option, we supply a new aftermarket NA30 replacement designed to fit the existing NA30 location. It isn't intended to change or upgrade the original setup. Instead, it gives you a replacement with the physical configuration and electrical ratings needed for compatible equipment.

At just 1 inch wide, the NA30 keeps the compact footprint these applications require. Overall dimensions are 3.38 inches high, 1 inch wide, and 2.31 inches deep. If you're replacing an existing breaker, check the part number, connection style, dimensions, amperage, voltage, and interrupting rating before installation. It's a straightforward replacement that's built to last in its intended application.

Key Features and Benefits

  • 30 amp, single-pole configuration
  • Rated 10k AIC at 120VAC
  • Stab-On connection
  • Thermal magnetic design
  • Type NA breaker
  • 1-inch-wide footprint
  • New aftermarket replacement for compatible NA30 applications
  • Designed around the form, fit, and function of the existing NA30 location
  • Built to last for its intended use

Technical Specifications

  • Part Number: NA30
  • Type: NA
  • Amperage: 30 Amps
  • Poles: 1
  • A.I.C. Rating & Voltage: 10k @ 120VAC
  • Connection: Stab-On
  • Breaker Type: Thermal Magnetic
  • Height: 3.38"
  • Width: 1.0"
  • Depth: 2.31"
  • Ship Weight: 1.75 lbs.

Material Compliance and Certifications

The supplied specifications included no specific material compliance information or third-party certifications. Because of that, this description does not make claims regarding UL, CSA, RoHS, or other certifications. If your application requires a particular listing or certification, confirm it for the exact breaker being supplied.

Where It Works Best

The NA30 is intended for compatible legacy electrical equipment requiring a 30 amp, single-pole Type NA breaker with a Stab-On connection and a 10k AIC rating at 120VAC.

It's a sensible choice when you're trying to match an existing NA30 installation rather than alter the original equipment configuration. Check the breaker requirements and physical fit for the specific equipment before installation.
