MPD2200 - 200 Amp Circuit Breaker

MPD2200 - 200 Amp Circuit Breaker

When you’re replacing a circuit breaker in existing or legacy electrical equipment, getting the form, fit, and electrical ratings right matters far more than simply finding something that looks similar. The MPD2200 is a 200-amp, 2-pole, 120/240V Type MD-T circuit breaker with a manufacturer-specified 10 kA interrupt rating. For maintenance teams, electricians, and facility personnel working with older equipment, the MPD2200 provides a clearly defined combination of catalog number, amperage, voltage, pole count, breaker type, and interrupting capacity to compare against the breaker being replaced.

Key Features and Benefits

• 200A current rating — Manufacturer technical data identifies the MPD2200 as a 200-amp circuit breaker.
• 2-pole configuration — Provides the specific two-pole arrangement required by compatible electrical distribution equipment.
• 120/240V rating — A clearly defined voltage rating makes it easier to compare the breaker with existing system requirements.
• Type MD-T — Clearly identifies the breaker type, an important detail when determining compatibility with legacy equipment.
• Non-reversible branch main configuration — Helps distinguish the MPD2200 from reversible configurations that may have similar electrical ratings.

Technical Specifications

• Catalog Number / MFN: MPD2200

• Article Number: US2:MPD2200

• Product Type: Circuit Breaker

• Product Designation: BREAKER 200A 2P 120/240V 10K MD-T

• Type: MD-T

• Configuration: Branch Main Breaker, Non-Reversible

• Amperage Rating: 200A

• Number of Poles: 2

• Voltage Rating: 120/240V

• Interrupt Rating: 10 kA

• Net Weight: 1.653 lb

• UPC: 040892006407

• Commodity Code: 8536200020

• Country of Origin: Mexico

• Dangerous Goods Classification: No


Material Compliance and Certifications

The supplied product information does not identify a specific UL, CSA, or other third-party certification for the MPD2200, so do not assume certification based solely on the catalog number or product family.

Where It Works Best

The MPD2200 circuit breaker is most relevant for existing and legacy electrical distribution equipment that specifically requires a 200A, 2-pole, 120/240V Type MD-T non-reversible branch main breaker with a 10 kA interrupt rating. The manufacturer describes this breaker family for load center mains and feeder applications, making those specifications useful checkpoints when servicing compatible equipment.
