MH36700 - 700 Amp Circuit Breaker

MH36700 - 700 Amp Circuit Breaker

Choosing the right 700 amp circuit breaker for your existing I-Line panelboard means checking the full specification—not just a familiar part number. The MH36700 is a 700 amp, 3-pole thermal magnetic molded case circuit breaker identified for use with compatible I-Line panelboards. Taken together, its MH type, amperage, pole configuration, voltage-specific interrupting ratings, dimensions, and intended I-Line panelboard application provide the practical information needed to evaluate it as a form, fit, and functional replacement candidate. Its solid molded-case construction is built to last when the breaker is correctly selected, installed, and maintained for its intended electrical application.

Key Features and Benefits

• 700 Amp Rating: Rated at 700A for applications that specifically require this current rating.
• Three-Pole Configuration: The 3-pole design is a key compatibility point when matching the MH36700 to existing electrical equipment.
• For I-Line Panelboards: This breaker is specifically identified for use with I-Line panelboards, helping narrow the compatibility check during replacement work.
• Thermal Magnetic Design: The supplied product information identifies the MH36700 as a thermal-magnetic molded-case circuit breaker.
• 60Hz, 40°C Specifications: Both ratings are provided for straightforward comparison with existing installation requirements.

Technical Specifications

• Part Number: MH36700

• Type: MH

• Product Type: Thermal Magnetic Molded Case Circuit Breaker

• Intended Application: I-Line Panelboards

• Amperes: 700A

• Poles: 3

• A.I.C. Rating & Volts: 25k @ 600VAC; 65k @ 480VAC; 65k @ 240VAC

• Frequency: 60Hz

• Temperature Rating: 40°C

• Dimensions: 9.00"W x 16.00"L x 4.54"D

• Height: 16.00 in.

• Width: 9.0 in.

• Depth: 4.54 in.

• Approximate Shipping Weight: 45.00 lbs.


Material Compliance and Certifications

The supplied specifications for the MH36700 did not include any specific UL, CSA, IEC, RoHS, REACH, HACR, or other certification or material-compliance information. Do not assume those details based on another breaker in the MH family.

Where It Works Best

The MH36700 700 amp circuit breaker is a form, fit, and functional replacement candidate for existing or legacy I-Line panelboard applications that require an MH-type, 700A, 3-pole thermal magnetic molded case circuit breaker with matching electrical and physical characteristics.

Compatibility should include ratings above 700A. Confirm the system voltage against the appropriate interrupting rating—25k at 600VAC, 65k at 480VAC, or 65k at 240VAC—along with the 60Hz frequency, 40°C rating, and 9.00" W x 16.00"L x 4.54"D physical dimensions.
