With a replacement trip unit, getting the small details right is what makes the part useful. The MES3800LSG is an 800-amp, three-pole electronic molded case circuit breaker accessory trip unit identified for Series C equipment. Its LSG trip type and specified ground-fault protection are important identifiers when comparing the unit with your existing electrical assembly. For existing or legacy equipment requiring these exact characteristics, it can be considered a form, fit, and functional replacement candidate after you review the complete application specifications. Solid construction is built to last when you select, assemble, install, and maintain the trip unit correctly.

Key Features and Benefits

• 800 Amp Rating: Rated at 800A for compatible electrical equipment requiring this specific trip-unit amperage.
• Three-Pole Configuration: Provides the three-pole arrangement specified for the MES3800LSG.
• Electronic Trip Unit: The product specifications explicitly identify electronic operation.
• LSG Trip Type: The LSG designation is a key specification to match when identifying a replacement trip unit.
• Ground-Fault Protection: The manufacturer's stated protection specification includes ground-fault protection.
• Series C: Intended for compatible Series C equipment where the complete application requirements match.
• Clearly Identified Accessory: This product is a molded case circuit breaker accessory trip unit rather than a complete circuit breaker, an important distinction when sourcing replacement electrical components.
• UL Listed: The MES3800LSG carries the supplied UL Listed certification.

Technical Specifications

• Catalog Number: MES3800LSG

• Global Catalog Number: MES3800LSG

• Product Name: Molded Case Circuit Breaker Accessory Trip Unit

• Product Type: Molded Case Circuit Breaker Accessory

• Type: Electronic

• Series: Series C

• Amperage Rating: 800A

• Number of Poles: Three-pole

• Trip Type: LSG

• Protection: Ground fault

• Product Length/Depth: 7 in.

• Product Height: 4 in.

• Product Width: 4 in.

• Product Weight: 4 lb.

• UPC: 782114371374


Material Compliance and Certifications

• Certification: UL Listed
• Compliance: Contact Manufacturer
• Additional Material Compliance: Specific RoHS, REACH, or other material-compliance information was not supplied for this catalog number and should not be assumed.

Where It Works Best

The MES3800LSG 800A electronic trip unit is best suited as a replacement candidate in existing or legacy electrical equipment that specifically calls for a Series C, three-pole, 800A electronic trip unit with an LSG trip type and ground-fault protection. Because this is an accessory trip unit rather than the complete molded-case circuit breaker, you must consider the entire breaker assembly and application when checking compatibility.
