MD175V - 175A Circuit Breaker

MD175V 175A Circuit Breaker

The MD175V Circuit Breaker is engineered to deliver exceptional protection for residential electrical systems, designed with a 175-amp capacity and a 10,000 AIC rating at 120/240VAC. This two-pole breaker features a robust thermal magnetic design, ensuring reliable defense against overloads and short circuits. Its plug-in installation is made easy with staggered lugs, and the wire enters the lug terminals parallel to the handle's action, providing a secure and efficient connection within your existing panel. The compact dimensions make it an ideal fit for maintaining residential electrical systems that require consistent and reliable performance.

Key Features and Benefits:

• High-Capacity Protection: Supports a 175-amp load with a 10k AIC rating, making it an ideal choice for residential electrical systems requiring substantial protection.
• Thermal Magnetic Technology: Offers dual protection against both overloads and short circuits, ensuring your home's electrical safety is uncompromised.
• Effortless Installation: The plug-in design, coupled with staggered lugs and parallel wire entry, simplifies installation, ensuring a reliable connection within your residential panel.

Technical Specifications:

• Amperage: 175 Amps
• Poles: 2
• Voltage Rating: 120/240 VAC
• Interrupting Rating: 10k AIC
• Frame Type: MDV
• Dimensions: 2.00" Width x 7.06" Length x 3.25" Depth
• Weight: 4.5 lbs

Material Compliance and Certifications:

• The MD175V Circuit Breaker is constructed to meet rigorous industry standards, ensuring it complies with all necessary safety regulations for residential use. This certification provides homeowners with the confidence that their electrical system is protected by a high-quality, dependable component.

Suitability:

• This MD175V Circuit Breaker is specifically designed for maintenance purposes, serving as a reliable replacement part for existing residential electrical systems that require a 175-amp, 10k AIC breaker. Perfectly suited for maintaining the integrity and safety of your current electrical setup.
