LT3300T - 300 Amp Trip Unit

LT3300T - 300 Amp Trip Unit

The LT3300T is a 300-amp, three-pole thermal magnetic trip unit for compatible Series C, Frame J-K molded case circuit breaker equipment. When you're maintaining an existing electrical system, the details matter: amperage, frame size, pole count, trip type, and physical fit all need to line up with the application.

Key Features and Benefits

• 300 Amp Rating: Rated at 300A for compatible electrical equipment requiring this specific trip-unit amperage.
• Three-Pole Configuration: Built for applications calling for a three-pole LT trip unit.
• Thermal Magnetic Trip: Uses a non-interchangeable thermal magnetic trip configuration.
• Frame J-K Compatibility: Specified for Frame J-K equipment, an important detail when checking replacement suitability.
• Series C: Identified as part of the Series C product family.
• LT Circuit Breaker Type: The LT designation provides another key reference when matching the trip unit to existing equipment.

Technical Specifications

• Catalog Number: LT3300T

• Global Catalog Number: LT3300T

• UPC: 786679580042

• Product Type: Molded case circuit breaker accessory

• Type: Trip unit

• Circuit Breaker Type: LT

• Series: Series C

• Frame Size: Frame J-K

• Trip Type: Non-interchangeable thermal-magnetic

• Amperage Rating: 300A

• Number of Poles: Three-pole

• Product Length/Depth: 8.5 in.

• Product Height: 5.7 in.

• Product Width: 5.3 in.

• Product Weight: 2.85 lb

• Certification: UL Listed


Material Compliance and Certifications

The LT3300T is UL Listed, according to the supplied manufacturer specifications. That listing is useful when confirming whether the trip unit meets the requirements of the equipment, facility, or electrical project where it will be used.

Where It Works Best

The LT3300T 300A trip unit is best suited to compatible Series C, Frame J-K molded case circuit breaker equipment that specifically calls for an LT-type, three-pole, 300 amp, non-interchangeable thermal magnetic trip unit. It makes particular sense in existing or legacy electrical systems where maintaining the correct equipment configuration is the priority.
