LGB3B100B - 100Amp Circuit Breaker

LGB3B100B - 100Amp Circuit Breaker

The Siemens LGB3B0100B is a state-of-the-art, low-voltage circuit breaker designed to provide exceptional protection and performance in demanding environments. This G-frame circuit breaker is engineered with a thermal-magnetic trip unit, making it ideal for commercial and industrial applications where precision and durability are paramount. With a robust breaking capacity, the LGB3B0100B can handle up to 14KAIC at 600Y/347V and an impressive 65KAIC at 480Y/277V, ensuring your electrical system remains secure under high fault conditions.

Key Features and Benefits:

• High Breaking Capacity: Rated to handle severe fault conditions, ensuring maximum safety and operational continuity.
• Thermal-Magnetic Trip Unit: Combines both thermal and magnetic tripping to respond to a wide range of overcurrent scenarios effectively.
• Compact Design: With dimensions of 3 x 5.4 x 2.8 inches, it fits seamlessly into low-voltage panelboards without sacrificing space or functionality.
• Load Side Lugs Only: Featuring TC1GG20 load side lugs, this circuit breaker supports wire ranges from 8 to 1/0 AWG, compatible with both copper and aluminum conductors.

Technical Specifications:

• Amperage: 100A
• Poles: 3
• Voltage Rating: 600Y/347V (14KAIC);åÊ480Y/277V (65KAIC)
• Frame Size: LGB
• Dimensions: 3 inches (W) x 5.4 inches (H) x 2.8 inches (D)
• Weight: 2.756 lbs
• Wire Range: 8 - 1/0 AWG (Copper/Aluminum)

Material Compliance and Certifications:

• Compliance: The Siemens LGB3B0100B circuit breaker complies with rigorous UL standards, ensuring it meets the highest safety and performance benchmarks. This breaker is UL Listed, providing assurance of its quality and adherence to industry safety standards.

Suitability:

• This circuit breaker is perfectly suited for a variety of settings, from industrial manufacturing plants to commercial buildings. The Siemens LGB3B0100B is designed to deliver reliable and efficient performance. Its high breaking capacity makes it particularly effective in installations where overcurrent protection is critical. Whether you are upgrading an existing panel or designing a new electrical system, this breaker provides the robust protection and operational flexibility you need.

Explore the Siemens LGB3B0100B and experience unparalleled safety and performance for your electrical infrastructure.
