LGB3B030B - 30Amp Circuit Breaker

LGB3B030B - 30Amp Circuit Breaker

A breaker can have the right amperage and still be the wrong fit for a panelboard. That's why the LGB3B030B details matter. This 30A, 3-pole LGB G-frame circuit breaker is designed for compatible low-voltage panelboard applications and uses a thermal-magnetic trip unit. Electrical ratings include 65 kA at 480Y/277V and 14 kA at 600Y/347V. If you're maintaining existing electrical equipment, those ratings give you a useful starting point, but don't stop there.

Key Features and Benefits

• 30A, 3-pole configuration for compatible low-voltage panelboard applications
• LGB G-frame design provides an important identification point when matching an existing breaker
• Thermal-magnetic trip unit provides the specified overload and short-circuit protection
• UL Listed LGB frame
• Uses TC1Q1 load-side lugs only
• Accepts 14–10 AWG copper or aluminum (Cu/Al) conductors
• Well suited to maintenance and functional replacement where the equipment requires the specified LGB3B030B configuration

Technical Specifications

• Catalog Number: LGB3B030B

• Article Number: US2\:LGB3B030B

• Product Type: Low-Voltage Panelboard-Mount Circuit Breaker

• Frame: LGB / G Frame

• Ampere Rating: 30A

• Number of Poles: 3

• Trip Type: Thermal-Magnetic

• Interrupting Rating at 480Y/277V: 65 kA

• Interrupting Rating at 600Y/347V: 14 kA

• Terminal Arrangement: Load-Side Lugs Only

• Load Lug Type: TC1Q1

• Wire Range: 14–10 AWG

• Conductor Compatibility: Copper / Aluminum (Cu/Al)

• Dimensions: 3"W x 5.4"H x 2.8"D

• Net Weight: 2.756 lb

• Country of Origin: Mexico

• UPC: 887621220242

• Commodity Code: 8536200020

• Export Classification: ECCN EAR99 / AL N

• Dangerous Goods: No


Material Compliance and Certifications

The supplied manufacturer specifications identify the LGB frame as UL Listed. Environmental information associated with the LGB3B030B also references WEEE (2012/19/EU) take-back obligations and provides information related to REACH Article 33.

Where It Works Best

The LGB3B030B 30A 3-pole circuit breaker is a practical fit for existing and legacy low-voltage panelboards designed around this LGB G-frame configuration. Replacement work is where careful specification matching pays off. You aren't simply looking for another 30A breaker; you're looking for the electrical and physical configuration the equipment requires.

Start with the 30A rating and three-pole arrangement, then verify that the application calls for an LGB G-frame breaker with a thermal-magnetic trip unit. System requirements should correspond with the breaker's interrupting ratings of 65 kA at 480Y/277V and 14 kA at 600Y/347V.
