KHL36150 - 150 Amp Circuit Breaker

KHL36150 - 150 Amp Circuit Breaker

When an existing electrical system calls for a KHL36150, it helps to have the full specification in front of you rather than relying on the 150-amp rating alone. This is a 3-pole Type KHL molded-case circuit breaker with a thermal-magnetic configuration, 60Hz operation, and a 40°C temperature rating. For older or legacy systems, checking these details up front can help determine whether the breaker provides the required form, fit, and function.

Key Features and Benefits

• 150A, 3-pole configuration for applications requiring these specific electrical characteristics.
• Type KHL molded case circuit breaker with a thermal-magnetic configuration.
• Line and load lugs are included, making the connection arrangement another specification you can verify against the existing breaker.
• Specified for 60Hz operation at 40°C.
• Well suited to compatible existing and legacy equipment when the part number, ratings, dimensions, and connection requirements match the application.


Technical Specifications

• Part Number: KHL36150

• Breaker Type: Molded Case Circuit Breaker

• Type: KHL

• Configuration: Thermal Magnetic

• Amperage: 150A

• Poles: 3

• Frequency: 60Hz

• Temperature Specification: 40°C

• Interrupting Rating at 600VAC: 25k AIC

• Interrupting Rating at 480VAC: 35k AIC

• Interrupting Rating at 240VAC: 65k AIC

• Lugs: Line and Load Lugs Included

• Width: 4.50 in.

• Height/Length: 8.00 in.

• Depth: 3.69 in.

• Dimensions: 4.50"W x 8.00"L x 3.69"D

• Approximate Shipping Weight: 10.00 lbs.


Material Compliance and Certifications

Specific certification and material-compliance details were not provided for the KHL36150, so listings or standards such as UL, RoHS, or REACH shouldn't be assumed.

Where It Works Best

The KHL36150 is intended for situations where existing or legacy electrical equipment requires this particular 150-amp, 3-pole Type KHL configuration and the remaining specifications are compatible.

Before installation, put the breaker specifications side by side with the existing unit or equipment documentation. Check the KHL type, 150A rating, three poles, 4.50"W x 8.00"L x 3.69"D dimensions, thermal-magnetic configuration, 60Hz frequency, 40°C specification, and line and load lug requirements.
